Analog Inputs – Internal
Settings for internal analog objects of the device.
Only specific settings and differences to the normal are described below. See Chapter 6.4 for a general
description of the configuration options.
Settings – Internal:
Parameter Description
Unit temperature Object linked to temperature measurement inside
the device.
Default:
Type and Deadband – Internal:
Object Type / Deadband
Normalized [0-100 %]
Normalized [0-120 %]
Float [SI]
Unit temperature
Scaled [SI*1]
Scaled [SI*10]
Scaled [SI*100]
Unit temperature Deadband [%]
Protrol AB
Alfagatan 3
431 49 Mölndal, SWEDEN
- Type: Float [SI]
- No time stamp
- Deadband: 1.0 %
Description
Normalized to 100 degrees Celsius.
Normalized to 120 degrees Celsius.
Floating point corresponding to Celsius degrees.
Integers corresponding to Celsius degrees.
Integers corresponding to 0.1 Celsius degrees
Integers corresponding to 0.01 Celsius degrees.
Set as a percentage of 100 degrees Celsius.
25
Factory value
address
3001
