Type and deadband – Detector n:
Object
Lx Current
Lx Current
LN Current
LN Current
Max Fault Current
Max Current
Max Current
Avg Current Period
Avg Current Period
Fault Phase
Fault Phase
Protrol AB
Alfagatan 3
431 49 Mölndal, SWEDEN
Type / Deadband
Normalized [0-100 %]
Normalized [0-120 %]
Float [SI]
Scaled [SI*1]
Scaled [SI*10]
Scaled [SI*100]
Deadband [%]
Type
Deadband
Normalized [0-100 %]
Normalized [0-120 %]
Float [SI]
Scaled [SI*1]
Scaled [SI*10]
Scaled [SI*100]
Deadband [%]
Type
Deadband
Type
Deadband
Float [SI]
Scaled [SI*1]
Deadband
Description
Normalized primary current according to CT ratio.
Example: CT ratio = 300/1
Value 0  0 A
Value 1.0  300 A
Normalized primary current according to CT ratio times 1.2.
Example: CT ratio = 300/1
Value 0  0 A
Value 1.0  360 A
Primary current in Amperes, as floating point.
Primary current in Amperes, as integer.
Primary current in 0.1 Amperes, as integer
Primary current in 0.01 Amperes, as integer
Set as a percentage of CT ratio.
Example: CT ratio = 300/1
1 %  3 A
Identical to "Lx Current"
Identical to"Lx Current"
Normalized primary current according to CT ratio times 10.
Example: CT ratio = 300/1
Värde 0  0 A
Värde 1.0  3000 A
Normalized primary current according to CT ratio times 12.
Example: CT ratio = 300/1
Värde 0  0 A
Värde 1.0  3600 A
Primary current in Amperes, as floating point.
Primary current in Amperes, as integer.
Primary current in 0.1 Amperes, as integer
Primary current in 0.01 Amperes, as integer
Set as a percentage of CT ratio times 10.
Example: CT ratio = 300/1
1 %  30 A
Identical to "Lx Current" ovan.
Identical to "Lx Current" ovan.
Identical to "Lx Current" ovan.
Identical to "Lx Current" ovan.
Faulty phase, as floating point.
Faulty phase, as integer.
Not used.
