All binary inputs can be setup in the same manner. Beneath is a general description.
For more information on each specific object, please refer to the chapter that describes it.
Parameter
Description
Type
Settings – Blocked
Settings – Negative
Settings – Time tagged
Delay
Address 8
Address 16
Binary Inputs – Input 1-16
Settings for binary objects connected to physical inputs on the device, as well as IRF.
Only specific settings and differences to the normal are described below. See chapter 6.2 for a general
description of the various configuration options.
All objects have Delay set to 0 ms from the factory.
Settings – Input 1-16:
Parameter Description
Object linked to the ACN button on the front panel.
Ack button
Can only have the type single indication.
Input n Object connected to physical input n.
Input 16 Objects connected to physical input 16.
Can only have the type single indication.
IRF Indication for internal error.
Can only have the type single indication.
Protrol AB
Alfagatan 3
431 49 Mölndal, SWEDEN
Description
Brief descriptive name for the object.
Type of indication; Simple or Double.
The signal is blocked, i.e. no value / status is sent to the
remote end.
Also applies to "interrogation" (status request).
The signal is inverted, i.e. a high signal is transmitted with
status low to remote end.
The signal is timestamped upon change. The time is also
sent to the remote end.
Number of milliseconds that the signal should be changed
before a message is sent to the remote end. Applies to a
positive change state change (0 -> 1). When Settings –
Negative has been chosen, the opposite applies.
Upper octet of the address. Decimal.
Lower octets of the address. Decimal.
20
Range
-
Single point,
Double point
Yes or No
Yes or No
Yes or No
0 ... 65 535
0 ... 255
0 ... 65 535
Factory value
address
100
10n
116
117
