Analog Inputs – Detector x
This subtab contains settings for analog inputs connected to detector functions.
See chapter 6.4 for a general description of the various configuration options.
All objects are set to the Normalized [0-100%] type, except Fault Phase, and a 10% deadband from factory.
Current values are given as primary values.
For more information on the detector functions and the various signals see chapter 7.
Settings – Detector x:
Parameter
L1 Current
L2 Current
L3 Current
LN Current
Max Fault Current
Max Current
Avg Current Period
Fault Phase
Protrol AB
Alfagatan 3
431 49 Mölndal, SWEDEN
Description
Measured current (rms) at input L1 / Ia.
Measured current (rms) at input L2 / Ib.
Measured current (rms) at input L3 / Ic.
Calculated neutral current (rms).
Maximum fault current (rms), I>/I>>
Maximum current (rms).
Average current value (rms), 15 min.
Incorrect phase / phases.
The following values can be sent:
- 0,1,2,3,12,13,23,123
Can only be of the types:
- "Float [SI]" or "Scaled [SI * 1]"
26
Factory value
address
3x01
3x02
3x03
3x04
3x05
3x06
3x07
3x08
Phone: +46 31 45 82 00
internet: www.protrol.se
e-mail: info@protrol.se
Ver 1909
