4.3
Login
After connecting to the Protrol device, a login screen is displayed. This includes information about the
connected Protrol device and the input field for logging in.
Figure 6.
The login field of the web server.
The following standard users can be selected:
User
Password
status
status
config
config
admin
availability
4.4
Startup page and device information
After logging in, the home page is displayed. This includes status and information about the connected
device, as well as tabs for other functions.
At the bottom of all web pages, even on the login page, there is the unit's unique ID number and version on
software, see Figure 6. Copy the information field and attach it to the support case or complaint.
Protrol AB
Alfagatan 3
431 49 Mölndal, SWEDEN
User properties
Displaying settings
Download of disturbance files
Display / change of normal settings
Download of disturbance files
Firmware upgrade
Same as config, and in addition user administration and password
Display / change of special settings
12
Ver 1909
