DMX Protocol (30 Channel Mode)

DMX Channels CH1 + CH2 + CH3 control RGB Output 10
0-255
0-255
0-255
DMX Channels CH4 + CH5 + CH6 control RGB Output 9
0-255
0-255
0-255
DMX Channels CH7 + CH8 + CH9 control RGB Output 8
0-255
0-255
0-255
DMX Channels CH10 + CH11 + CH12 control RGB Output 7
0-255
0-255
0-255
DMX Channels CH13 + CH14 + CH15 control RGB Output 6
0-255
0-255
0-255
DMX Channels CH16 + CH17 + CH18 control RGB Output 5
0-255
0-255
0-255
DMX Channels CH19 + CH20 + CH21 control RGB Output 4
0-255
0-255
0-255
DMX Channels CH22 + CH23 + CH24 control RGB Output 3
0-255
0-255
0-255
DMX Channels CH25 + CH26 + CH27 control RGB Output 2
0-255
0-255
0-255
DMX Channels CH28 + CH29 + CH30 control RGB Output 1
0-255
0-255
0-255
CH1 Red 0 – 100%
CH2 Green 0 – 100%
CH3 Blue 0 – 100%
CH4 Red 0 – 100%
CH5 Green 0 – 100%
CH6 Blue 0 – 100%
CH7 Red 0 – 100%
CH8 Green 0 – 100%
CH9 Blue 0 – 100%
CH10 Red 0 – 100%
CH11 Green 0 – 100%
CH12 Blue 0 – 100%
CH13 Red 0 – 100%
CH14 Green 0 – 100%
CH15 Blue 0 – 100%
CH16 Red 0 – 100%
CH17 Green 0 – 100%
CH18 Blue 0 – 100%
CH19 Red 0 – 100%
CH20 Green 0 – 100%
CH21 Blue 0 – 100%
CH22 Red 0 – 100%
CH23 Green 0 – 100%
CH24 Blue 0 – 100%
CH25 Red 0 – 100%
CH26 Green 0 – 100%
CH27 Blue 0 – 100%
CH28 Red 0 – 100%
CH29 Green 0 – 100%
CH30 Blue 0 – 100%
