- Page 1 MANUAL ENGLISH Truss Booster RDM 1-6 V1 Ordercode: 50794 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Truss Booster RDM 1-6 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Overview ..................................7 Front .................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Truss Booster RDM 1-6 ● Pro power cable (1,5 m) ●... - Page 4 ● If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service. ● For adult use only. The device must be installed out of the reach of children. Never leave the unit running unattended.
-
Page 5: Operating Determinations
Truss Booster RDM 1-6 Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● To eliminate wear and improve lifespan, during periods of non-use, completely disconnect from power via breaker or by unplugging. -
Page 6: Connection With The Mains
Truss Booster RDM 1-6 The Truss Booster RDM 1-6 can be mounted to any kind of truss with a clamp or with the included Velcro straps. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. -
Page 7: Return Procedure
Truss Booster RDM 1-6 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 8: Description Of The Device
Description of the device Features The Truss Booster RDM 1-6 is a compact and nifty solution for splitting/boosting DMX and RDM signals. It can be mounted to a truss or pipes with the included bracket or Velcro straps. The rubber protection- rings on each side of the rugged housing makes this booster ideal for road productions. -
Page 9: Front
Truss Booster RDM 1-6 Front Fig. 02 01) Mounting bracket 02) LED signal indicator 03) 5-pin DMX/RDM signal connector THRU 04) DMX/RDM mode selection button Press the button to choose between DMX and RDM. Note: RDM is an enhancement of DMX-512 protocol that allows bi-directional communication between a lighting controller and RDM compliant devices. -
Page 10: Back
14) 6 x 5-pin DMX/RDM signal connector OUT Installation Remove all packing materials from the Truss Booster RDM 1-6. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 11: Control Modes
Truss Booster RDM 1-6 Control Modes Multiple Truss Boosters (DMX/RDM control) 01) Fasten the Truss Boosters to a truss. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 5-pin XLR cable to connect the Truss Boosters and other devices. -
Page 12: Fixture Linking
Truss Booster RDM 1-6 Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 13: Maintenance
Truss Booster RDM 1-6 Maintenance The Showtec Truss Booster RDM 1-6 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. - Page 14 Truss Booster RDM 1-6 Problem Probable cause(s) Solution ● Check if power is switched on One or more and cables are plugged in. No power to the fixture. fixtures do not function at all. Primary fuse blown. ● Replace fuse.
-
Page 15: Product Specifications
Truss Booster RDM 1-6 Product Specifications Model: Showtec Truss Booster RDM 1-6 Input voltage: 100–240 V AC, 50/60 Hz Power consumption: Outputs: 6 x 5-pin DMX/RDM OUT Control protocols: DMX-512/RDM Connections: Pro power connector IN(Blue)/OUT(Gray), 1 x 5-pin DMX/RDM IN, 1 x 5-pin... - Page 16 ©2019 Showtec...
