DMX Protocol (6 Channel Mode)

DMX Channel 1 + 2 + 3 control RGB Output 6 - 10
0-255
0-255
0-255
DMX Channel 4 + 5 + 6 control RGB Output 1 - 5
0-255
0-255
0-255

DMX Protocol (15 Channel Mode)

DMX Channels CH1 + CH2 + CH3 control RGB Output 9 and 10
0-255
0-255
0-255
DMX Channels CH4 + CH5 + CH6 control RGB Output 7 and 8
0-255
0-255
0-255
DMX Channels CH7 + CH8 + CH9 control RGB Output 5 and 6
0-255
0-255
0-255
DMX Channels CH10 + CH11 + CH12 control RGB Output 3 and 4
0-255
0-255
0-255
DMX Channels CH13 + CH14 + CH15 control RGB Output 1 and 2
0-255
0-255
0-255
CH1 Red 0 – 100%
CH2 Green 0 – 100%
CH3 Blue 0 – 100%
CH4 Red 0 – 100%
CH5 Green 0 – 100%
CH6 Blue 0 – 100%
CH1 Red 0 – 100%
CH2 Green 0 – 100%
CH3 Blue 0 – 100%
CH4 Red 0 – 100%
CH5 Green 0 – 100%
CH6 Blue 0 – 100%
CH7 Red 0 – 100%
CH8 Green 0 – 100%
CH9 Blue 0 – 100%
CH10 Red 0 – 100%
CH11 Green 0 – 100%
CH12 Blue 0 – 100%
CH13 Red 0 – 100%
CH14 Green 0 – 100%
CH15 Blue 0 – 100%
