Firegear FPB-25SFBSAWS-N Installation And Operating Instructions Manual
Fire pit burners with all weather electronic ignition system
Hide thumbs
Also See for FPB-25SFBSAWS-N:
- Installation and operating instructions manual (24 pages) ,
- Installation and operating instructions manual (28 pages) ,
- Installation and operating instructions manual (24 pages)
Table of Contents
Advertisement
Round Pan Style
AWS Model
FPB-25SFBSAWS-N
FPB-26DBSAWS-N
FPB-29DBSAWS-N
FPB-29RBSAWS-N
FPB-30SFBSAWS-N
FPB-33RBSAWS-N
FPB-34DBSAWS-N
FPB-40SFBSAWS-N
FPB-44DBSAWS-N
All Weather Electronic Ignition System (AWS)
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
This system requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation will void the warranty.
Warning: For Outdoor Use Only
Square Disc Style
25" Natural Gas, Square Flat Disc with 22" Spur Burner
26" Natural Gas, Round Flat Disc with 16" Spur Burner
29" Natural Gas, Round Flat Disc with 22" Spur Burner
29" Natural Gas, Round Pan with 22" Spur Burner
30" Natural Gas, Square Flat Disc with 22" Spur Burner
33" Natural Gas, Round Pan with 31" Spur Burner
34" Natural Gas, Round Flat Disc with 31" Spur Burner
40" Natural Gas, Square Flat Disc with 36" Spur Burner
44" Natural Gas, Round Flat Disc with 36" Spur Burner
Fire Pit Burners (FPB) with
INSTALLATION PRECAUTION:
DO NOT DISCARD. THIS MANUAL
HAS IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS.
LEAVE WITH THE HOMEOWNER.
MODEL:
SERIAL #:
Description
Round Disc Style
REV. 8-9-19 Page 1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Firegear FPB-25SFBSAWS-N
Summary of Contents for Firegear FPB-25SFBSAWS-N
- Page 1 Round Disc Style Round Pan Style Square Disc Style AWS Model Description FPB-25SFBSAWS-N 25” Natural Gas, Square Flat Disc with 22” Spur Burner FPB-26DBSAWS-N 26” Natural Gas, Round Flat Disc with 16” Spur Burner FPB-29DBSAWS-N 29” Natural Gas, Round Flat Disc with 22” Spur Burner FPB-29RBSAWS-N 29”...
- Page 2 CARBON MONOXIDE HAZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed area can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. WARNING DANGER If you smell gas: Do not store or use gasoline or other...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Specifications Carton Contents - Single Fire Feature Preparing a Non Combustible Structure Ventilation; High Elevation; Hard Piping Gas Pipe Sizing Chart Pre-Installation Check List for Single Installation Power Supply Location for Single Installation Burner Pan Preparation 10-11 Installing Valve Kit to Burner Pan 12-13 Installing Key Valve &... -
Page 4: Specifications
25/64 230,000 185,500 FPB-44DBSAWS-N 25/64 230,000 185,500 Table 2 Btu Specifications for Burner Spur by Firegear Outdoors Pressure Min. Inlet 3.5” WC (⅛ PSI) 8.0” WC (¼ PSI) Max. Inlet 14.0” WC (½ PSI) 14.0” WC (½ PSI) Normal Inlet 7.0” WC (¼ PSI) 11.0”... -
Page 5: Carton Contents - Single Fire Feature
CONTENTS These kits includes a valve and control system that is Shown below are three different fire pit styles that come certified by Lab Test for USA and Canada to meet ANSI with the All Weather Ignition System (AWS); depending Z21:.97-2014, CSA C22.2 No 3-M1998 (R2014) upon the model ordered. -
Page 6: Preparing A Non Combustible Structure
290,000 Btu’s. The system this manual for a Firegear burner. NOTE: Depending on features a built-in safety shut-off in case of flame loss and venting locations, do not place fire pit directly on grass, auto-relight. -
Page 7: Gas Pipe Sizing Chart
REFERENCE GAS PIPE SIZING CHART GAS PIPE SIZING NATURAL GAS : PIPE SIZING CHART Length of Pipe in Feet 1/2” 3/4” 1” 1 - 1/4” 1 - 1/2” 2” 2 - 2 1/2” 3” 4” • Natural Gas (NG) flow is given in 1237 2259 3640... -
Page 8: Pre-Installation Check List For Single Installation
Natural gas. To convert to Propane (LP) gas, the secondary pilot orifice must be changed. Power Supply - Firegear Outdoors offers one power supply for use with the FPB fire features. The power Manual Shut-off/Key Valve - The manual key valve... -
Page 9: Power Supply Location For Single Installation
PREPARING A NON-COMBUSTIBLE STRUCTURE FOR SINGLE INSTALL POWER SUPPLY LOCATION The GOE-30VDC power supply is to be installed inside the enclosure due to the wire length limitations. The power cord is 3-feet long the 30VDC leads to the valve are 3-feet long. See Fig. 5. Fig. - Page 10 PREPARING THE BURNER PAN FOR PILOT INSTALLATION Tab bent up 90° ALL PANS OR DISCS MUST BE REMOVABLE FOR SERVICE Pans or discs CAN NOT be installed in a manner to prevent them from being removed for service. Top coping material or top cap of fire feature MUST NOT overlap onto the pan or disc surface.
-
Page 11: Burner Pan Preparation
Secure the burner against the pan with a nut and washer then install the orifice and shown in Fig. 12. Firegear Spur burner and orifice shown. Note: The AWS valve is set up for ½” fittings. If your burner is ¾”... -
Page 12: Installing Valve Kit To Burner Pan
INSTALLING VALVE KIT TO BURNER PAN INSTALLING GAS VALVE TO BURNER Thread the Outlet side of the gas valve to the orifice and secure it into position. Ensure the brass pilot fittings are Invert the burner pan upside down and install the heat facing the pilot area for a convenient connection. -
Page 13: Installing Key Valve & Remote Control
INSTALLING VALVE KIT TO BURNER PAN The pilot assembly has two pilots inside the perforated INSTALLING MANUAL KEY VALVE hood. One uses a flared fitting to connect to the valve box The key valve contents: (1) key valve, (1) 12-inch key and an the other pilot uses a compression fitting. - Page 14 FINAL PREPARATIONS KEY VALVE- REMOTE - MEDIA INSTALLATION Note: A 1¼” x 2” black iron or galvanized coupler/nipple Note: An extra red jumper wire is provided to extend either (not supplied) can be used as a spacer between the manu- one of the red wires of the FG-1420-AOD remote control al valve and the valve flange to add additional receiver (if needed).
-
Page 15: Installing Media
FINAL PREPARATIONS KEY VALVE- REMOTE - MEDIA INSTALLATION INSTALLATION OF MEDIA INTO BURNER PAN Install lava rock into the burner pan. Ensure the lava rock is a minimum of 1-inch diameter for proper operation. Note: Do not pour Lava Rock directly from bag. It should be placed naturally and NOT packed in tight. -
Page 16: Wiring Diagram For Single Installation
FINAL PREPARATIONS WIRING DIAGRAMS FOR SINGLE INSTALL Valve Box Weather Proof GFI Box FG-1420-AOD Receiver LEARN GOE-30VDC Power Supply Fig. 24 Wire diagram of AWS system with FG-1420-A OD remote control receiver Non-Combustible Enclousure Spur Burner Flat Disc Heat Flex Frame Flex Frame Shield Weather... -
Page 17: Operating- Lighting Instructions
OPERATION & LIGHTING CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance. WARNING: Do not use this appliance if any part has been under water. -
Page 18: Replacements Parts
AWS REPLACEMENT PARTS GOE-30DCV Items are not to scale Weatherproof Cover/Lid Junction Box FPB Fire Pits with AWS System REV. 8-9-19 Page 18... -
Page 19: Replacement Parts List
AWS REPLACEMENT PARTS LIST Qty. Description Part Number Item Ignition Control Box (Valve box only) FG-ICB Pilot Burner Assembly (Complete pilot assembly and wires) FG-PBA 30VDC Power Supply for single fire feature (10-feet from pools) GOE-30DCV Primary Pilot Burner Gas Line (24-inch) FG-PPBG Secondary Pilot Burner Gas line (24-inch) FG-SPBG... -
Page 20: Troubleshooting
TROUBLESHOOTING Sequence of Operation Fire Feature Turned ON First Pilot with Hot Surface Igniter Heats Up and Glows (Approx. 10 seconds) Secondary Pilot Opens; “Click” is Heard; Gas is Released to Burner Fire Feature is Lit Until Turned OFF The system is designed to relight itself if blown out. It will try (3) times to relight before it goes into a “hard”... -
Page 21: Trouble Shooting
TROUBLESHOOTING 3. Glow Plug Glows, But Does Not Ignite the Gas • Insufficient Power - If the glow plug is not getting enough power, it will not get ignite the gas. • Thin Wire - The recommended minimum wire gauge is 12AWG . If wire is less than 12-gauge there may not be enough power to get the igniter hot enough. -
Page 22: Troubleshooting
TROUBLESHOOTING 6. Fire Feature Cycles (Turns On and Off) Every Few Minutes • Gas Volume Insufficient – See symptom 5 page 29 for “Gas Volume Insufficient” for detailed explanation. • Oxygen Starvation (Pilot Burner) – See symptom 5 page 29 for “Oxygen Starvation” for detailed explanation. •... -
Page 23: Optional Accessories
Match Throw (MT) Burning Spur fire pit to use with kit listed above (sold separately). Note: See the Firegear Outdoors catalogue for a variety of fittings and flex connectors also available. FPB Fire Pits with AWS System REV. 8-9-19 Page 23... -
Page 24: Warranty
Lava Rock and Lava Stones are not covered by warranty For Commercial applications, the liability of Firegear Outdoors End User must provide a bill of sale, canceled check, or payment is limited to the express terms of this warranty. We expressly... - Page 25 FOR TECHNICAL SERVICE, CALL: (855) 498-8324 Firegear Outdoors 9230 Conservation Way Fort Wayne, IN 46809 Sales: (888) 672-8929 Sales Support: (888) 699-6167 Canadian Inquires: (877) 472-3923 Web Site: www.firegearoutdoors.com FPB Fire Pits with AWS System REV. 8-9-19 Page 25...
- Page 26 Having problems getting your Firegear Outdoors fire feature to operate? Don’t leave the job site! We want to help! Call 855.498.8324 for Technical Support between the hours of 8:00AM to 5:00PM EST. Text photos to 260.255.5750 or e-mail photos to support@skytechpg.com.
