Humanscale QuickStand Eco Installation Instructions Manual page 3

ST EP 1
• Place the base on a desk and remove
the plastic covers and set them aside.
Step 2
ST EP 2
Slide the main post onto the base by inserting the 2 tabs in the front and
secure the main post with 6 screws. Snap on the plastic covers removed in
• Slide the main post onto the base by inserting the 2 tabs in the front
step1. Rear cover first then front cover.
and secure the main post with 6 screws using the 4 mm hex key.
• Snap on the plastic covers removed in Step 1, placing the
rear cover first, then the front cover.
X 6
Place the base on a desk and remove the plastic covers and set them aside.
Step 2
Slide the main post onto the base by inserting the 2 tabs in the front and
secure the main post with 6 screws. Snap on the plastic covers removed in
step1. Rear cover first then front cover.
X 6
Slide the main pos
cure the main pos
Rear cover first the
3
