15" Full IP65 Stainless
Class I Division 2
Intel® Celeron® Bay Trail-M N2930, 1.83 GHz
R15IB3S-65EX
User Manual
Document Version 2.0
Document Part No. 9152150I1006
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R15IB3S-65EX and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate R15IB3S-65EX

Summary of Contents for Winmate R15IB3S-65EX

  • Page 1 15” Full IP65 Stainless Class I Division 2 Intel® Celeron® Bay Trail-M N2930, 1.83 GHz R15IB3S-65EX User Manual Document Version 2.0 Document Part No. 9152150I1006 Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    15" ATEX Panel PC R15IB3S-65EX User Manual Contents Preface ..........................4 About This User Manual ..................... 10 Chapter 1: Introduction ....................12 1.1 Overview ......................13 1.2 Product Features ....................13 1.3 Packing List ......................14 1.4 Appearance ......................15 1.4.1 Front View ....................
  • Page 3 Preface 5.3 Using Recovery Wizard to Restore Computer ............ 67 Chapter 6: Technical Support ................... 68 6.1 Software Developer Support ................69 6.2 Problem Report Form ..................69 Appendix..........................70 Appendix A: Product Specifications................70 Appendix B: Touchscreen ..................71...

  • Page 4: Preface

    15" ATEX Panel PC R15IB3S-65EX User Manual Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 5 Preface Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. NOTE: A note is used to emphasize helpful information IMPORTANT:...
  • Page 6 15" ATEX Panel PC R15IB3S-65EX User Manual Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges.
  • Page 7 Preface CAUTION/ATTENTION Use the recommended mounting apparatus to avoid risk of injury. Utiliser l’appareil de fixation recommandé pour éliminer le risque de blessure. WARNING! / AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer. Utiliser seulement les cordons d’alimentation fournis avec le produit.
  • Page 8 15" ATEX Panel PC R15IB3S-65EX User Manual Important Information Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. ...
  • Page 9 Preface Certifications and Standards Agency Standard for Marking Description Certification with ATEX Directive 94/9/EC; Independent 3rd party assessment (Notified Body: DEMKO) DEMKO 14 ATEX 1319472U EN 60079-0: 2012 / EditionEN 60079-11: 2012 / II 3 G Ex ic nA IIC Gc EditionEN 60079-15: 2010 Edition Independent 3rd party assessment IECEx UL 17.0030X...

  • Page 10: About This User Manual

    15" ATEX Panel PC R15IB3S-65EX User Manual About This User Manual This User Manual provides information about using the Winmate® 15-inch Stainless Panel PC. The documentation set provides information for specific user needs, and includes:  15-inch Stainless Panel PC User Manual – contains detailed description on how to use the display, its components and features.
  • Page 11 Preface...

  • Page 12: Chapter 1: Introduction

    15" ATEX Panel PC R15IB3S-65EX User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in this chapter.

  • Page 13: Overview

    Chapter 1: Introduction 1.1 Overview 15-inch Stainless Panel PC has a footprint of 15.6 x 12.2 inches and is less than two inches thick. The sturdy stainless steel housing has anti-corrosion protection and carries an IP65/NEMA4 sealing rating, meaning that it's completely protected against dust, and also protected against low- pressure water jets from all directions.

  • Page 14: Packing List

    15" ATEX Panel PC R15IB3S-65EX User Manual 1.3 Packing List Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately.

  • Page 15: Appearance

    Chapter 1: Introduction 1.4 Appearance 1.4.1 Front View 1.4.2 Side and Rear Views *OSD Panel is located under the enclosure.

  • Page 16: Led Indicators

    15" ATEX Panel PC R15IB3S-65EX User Manual 1.4.3 LED Indicators LED Type Status Description Power is on. Power Power is off. Blinking Storage activity (data is being read or written). System is idle. Storage 1.5 Mechanical Dimensions 1.5.1 Dimensions 15”...

  • Page 17: Hazardous Locations

    Chapter 1: Introduction 1.6 Hazardous Locations This equipment (R15IB3S-65EX) is primarily intended for use in Class I, Division 2 Groups A, B, C, and D; or non-hazardous locations only. It is suitable for use in oil, gas, and petrochemical manufacturing plants and locations where ignitable gases or vapor may be presented. This device is typically used for automation or control purposes.

  • Page 18: Chapter 2: Getting Started

    15" ATEX Panel PC R15IB3S-65EX User Manual Chapter 2: Getting Started This chapter provides information on how to connect the device to the source of power, connector pinouts and the guideline to turn on/off the Panel PC.

  • Page 19: Turning On And Off Your Device

    Chapter 2: Getting Started 2.1 Turning On and Off Your Device IMPORTANT: Power button is located under the enclosure on the rear side of the Panel PC. In order to access it, you need to open the enclosure. To Turn ON the device: 1.

  • Page 20: Adjusting The Lcd Display Brightness

    15" ATEX Panel PC R15IB3S-65EX User Manual Wait for your Panel PC to completely turn off before disconnecting the power cord (if necessary). 2.2 Adjusting the LCD Display Brightness 1. Tap the arrow on the system tray to display the hidden icons.

  • Page 21: Connectors

    Chapter 2: Getting Started 2.3 Connectors 2.3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device: • Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 22: Connecting The Interface

    15" ATEX Panel PC R15IB3S-65EX User Manual 2.3.2 Connecting the Interface This Panel PC comes with various interfaces located on the bottom panel. All of these connectors have been shipped with protective caps and tethers. If you wish to detach the tethers, the screws securing them to the bottom panel will need to be removed.
  • Page 23 Chapter 2: Getting Started IMPORTANT: Notice that when reinstalling the protective cap, it must be fully tightened to ensure the unit is properly sealed to meet the IP65 enclosure rating.

  • Page 24: Workstation

    15" ATEX Panel PC R15IB3S-65EX User Manual 2.3.3 Workstation 2.3.3.1 ATEX Zone 2 The connector cables are located under the enclosure. You need to connect wires first (refer to Chapter 1, section 1.3 to find the connector placement), install the pipe, insert the wires into the pipe opening, and then secure the cover box to the Panel PC.
  • Page 25 Chapter 2: Getting Started How to Install the Conduit Before you start installing the pipe, be sure that you have the following components: Slip Nut To secure “L” fitting adaptors. Stopper Plugs To close unused cable entry holes in explosion protected equipment.
  • Page 26 15" ATEX Panel PC R15IB3S-65EX User Manual M3x 6 Secure the plate to the bottom side Secure the cover on the top side Secure the cover on the bottom side M4 x 6 Secure the cover to both sides with the...

  • Page 27: Connector Pinouts

    Chapter 2: Getting Started 2.3.4 Connector Pinouts This Panel PC is equipped with four connectors which are IP65 level and fool-proofing design. Use only the cables that are included in the package. The pin assignments of the cables are as follows: IMPORTANT: Minimum input cables size is 18AWG, Minimum temperature rating of the cables is 105°C.
  • Page 28 15" ATEX Panel PC R15IB3S-65EX User Manual 2.3.4.3 RS-232 Cable (Optional RS-422/485) RS-232 Pin No. Symbols Color CN2-1 DCD-CON2 Green CN2-2 DSR-CON2 Brown CN2-3 RXD-CON2 CN2-4 RTS-CON2 Orange CN2-5 TXD-CON2 Blue CN2-6 CTS-CON2 White CN2-7 DTR-CON2 Purple CN2-8 RI-CON2 Yellow...
  • Page 29 Chapter 2: Getting Started 2.3.4.5 Power Adapter Pin No. Symbols Color CN2-1 Follow Adapter CN2-2 Follow Adapter CN2-3 Follow Adapter NOTE: The adapter is certified by UL, CUL TUV/GS CE, FCC, BSMI, EK, DOIR+C- TICK, CCC, PSE. 2.3.4.6 DC Power Cable (Open Wire) Pin No.

  • Page 30: Chapter 3: Installation

    15" ATEX Panel PC R15IB3S-65EX User Manual Chapter 3: Installation This chapter provides mounting guide for all available mounting options and hardware installation instructions. Pay attention to cautions and warning to avoid any damages.

  • Page 31: Cable Mounting Considerations

    Chapter 2: Getting Started 3.1 Cable Mounting Considerations For a nice look and safe installation, make sure cables are neatly hidden behind the Panel PC. Refer to Chapter 2, section 2.2.1 for the cable installation instruction. CAUTION/ ATTENTION Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury.

  • Page 32: Vesa Mount

    15" ATEX Panel PC R15IB3S-65EX User Manual 3.3.1 VESA Mount 3.3.1.1 Wall Mount Standalone Stainless Panel PC comes with VESA Mount solution. Follow the instruction below to complete mounting. Tools needed: Size Where used Quantity Appearance Screw M3x 6 Secure the metal plate...
  • Page 33 Chapter 2: Getting Started Mounting Steps: Step 1 First, you need to open the enclosure (box cover) to install VESA Plate to the enclosure of the Panel PC. *with customer’s bracket Exploded drawing: Item No. Description Top cover lid of the enclosure Bottom cover plate of the enclosure The conduit...
  • Page 34 15" ATEX Panel PC R15IB3S-65EX User Manual To open the enclosure, follow the steps below: Description Picture 1. Turn the Panel PC face down 2. Loosen screws (M4 x 6) on two metal plates that secure enclosure to the Panel PC from each side;...
  • Page 35 Chapter 2: Getting Started Step 2 After you opened the box cover, install VESA plate to the enclosure. To install VESA Plate, follow the steps below: Description Picture 1. Fasten four Philips M5x10 flathead screws from the inside of the box top cover.
  • Page 36 15" ATEX Panel PC R15IB3S-65EX User Manual Step 3 Align all the wires and insert into the pipe opening (refer to Chapter 2, section 2.3.3 for pipe installation instructions). Step 4 Secure the cover box on both top (three screws) and bottom (four screws) sides with M3 x 6 Philips flathead screws, and fasten the screws (M3 x 6) that secure box cover on the left and right sides;...
  • Page 37 Chapter 2: Getting Started Step 5 Fasten four Phillips M4x6 flathead screws on metal plates on both sides to secure Panel PC to the enclosure. Step 6 Carefully mount the device to the fixture (for ex. wall). Step 7 When the installation is complete; plug the power cord into a grounded AC outlet. Turn on the power.
  • Page 38 15" ATEX Panel PC R15IB3S-65EX User Manual 3.3.1.2 Swing Arm The device can be installed on a swing arm. You can purchase swing arm from RAM Mount. NOTE: You need to secure VESA Plate to the Panel PC enclosure with four...

  • Page 39: Chapter 4: Maintenance

    Chapter 4: Maintenance Chapter 4: Maintenance This chapter provides information on regular cleaning and maintenance procedures. Follow all the recommendations included in this chapter in order to ensure long product lifecycle.

  • Page 40: Cleaning The Display Screen

    15" ATEX Panel PC R15IB3S-65EX User Manual 4.1 Cleaning the Display Screen  Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles. Do not use acetone, ethyl alcohol, toluene, ethyl acid or methyl chloride to clear the panel.

  • Page 42: Chapter 5: Bios Setup Utility

    15" ATEX Panel PC R15IB3S-65EX User Manual Chapter 5: BIOS Setup Utility BIOS Setup Utility is a program for configuration basic Input / Output system settings of the Panel PC for optimum use. This chapter provides information on how to use BIOS setup, its...

  • Page 43: When And How To Use Bios Setup

    Chapter 5: BIOS Setup Utility 5.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. The prompt screen shows only few seconds, you need to press <Del>...

  • Page 44: Bios Menu

    15" ATEX Panel PC R15IB3S-65EX User Manual NOTE: You can press the F1, F2, F3, F4, –/+, and Esc keys by connecting a USB keyboard to your device. For items marked ► press <Enter> for more options. 5.3 BIOS Menu 5.3.1 Main Menu...

  • Page 45: Advanced Menu

    Chapter 5: BIOS Setup Utility 5.3.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. Important Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer.
  • Page 46 15" ATEX Panel PC R15IB3S-65EX User Manual BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI settings Enter Opens submenu F81866 Super IO Configures IO settings Enter Opens Configuration submenu Hardware Monitor Configures Hardware Enter Opens Monitor settings submenu...
  • Page 47 Chapter 5: BIOS Setup Utility 5.3.2.1 ACPI Settings BIOS Setting Description Setting Effect Option Enable ACPI Auto BIOS ACPI Enable/ Enables or Configuration Auto Disable Disables this Configuration function Enable Control Enable/ Enables or Hibernation hibernation Disable Disables this function...
  • Page 48 15" ATEX Panel PC R15IB3S-65EX User Manual 5.3.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen.
  • Page 49 Chapter 5: BIOS Setup Utility GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control. 5.3.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc.
  • Page 50 15" ATEX Panel PC R15IB3S-65EX User Manual 5.3.2.4 S5 RTC Wake Settings Wake System from S5 with fixed time setting Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time.
  • Page 51 Chapter 5: BIOS Setup Utility Wake system from S5 after dynamic time setting Select Dynamic Time to set the system to wake on the current time + increase minute (s). 5.3.2.5 CPU Configuration Press <Enter> to view current CPU configuration and make settings for the following sub-items.
  • Page 52 15" ATEX Panel PC R15IB3S-65EX User Manual BIOS Setting Description Setting Effect Option Socket CPU This item contains Enter Open sub-menu Information socket specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Disabled/ Enable/Disable...
  • Page 53 Chapter 5: BIOS Setup Utility 5.3.2.7 Thermal Configuration BIOS Setting Description Setting Option Effect Critical Trip Specifies the 90C, 87C, 85C, Select the Point temperature at which the 79C, 71C, disable OS will shut down the 63C,55C,47C, temperature for system 39C, 31C, 23C, the system to shut down...
  • Page 54 15" ATEX Panel PC R15IB3S-65EX User Manual 5.3.2.8 IDE Configuration BIOS Setting Description Setting Effect Option Serial- ATA Responsible for Enabled/ Enable or disable this function (SATA) supporting chipset Disabled drives with SATA interface. SATA Speed Allows forcing the Gen1...
  • Page 55 Chapter 5: BIOS Setup Utility Serial- ATA The option turns on or Enabled/ Turn on (Enabled) or turn off Port 0 off Port 0 of SATA Disabled (Disabled) Port 0 channels of standard IDE / SATA-controller chipset. SATA Port0 This feature that Enabled/ Enable or disable this function HotPlug...
  • Page 56 15" ATEX Panel PC R15IB3S-65EX User Manual 5.3.2.10 CSM Configuration BIOS Description Setting Effect Setting Option The Compatibility Support Module (CSM) is Enabled/ Enable or disable the Support a component of the UEFI firmware that Disabled Compatibility Support provides legacy BIOS compatibility by...
  • Page 57 Chapter 5: BIOS Setup Utility 5.3.2.11 USB Configuration...
  • Page 58 15" ATEX Panel PC R15IB3S-65EX User Manual BIOS Setting Description Setting Option Effect Legacy USB User can enable Disable Will keep USB Support or disable USB devices available port. only for EFI applications. Enable Enable all the USB devices USB 3.0 Support...
  • Page 59 Chapter 5: BIOS Setup Utility 5.3.2.12 Platform Trust Technology BIOS Setting Description Setting Option Effect fTPM Trusted Platform Module Enabled/Disabled Enables or parameters disables this function...
  • Page 60 15" ATEX Panel PC R15IB3S-65EX User Manual Security Configuration BIOS Description Setting Option Effect Setting Trusted Execution Enabled/Disabled Enables or Technology parameters disables this function TXE HMRFPO Enabled/Disabled Enables or HMRFPO parameters disables this function TXE Firmware Update Enabled/Disabled Enables or...
  • Page 61 Chapter 5: BIOS Setup Utility 5.3.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Setting Description Setting Option Effect High Precious Allow to set up Enabled/ Enables/Disables Timer High Precious Disabled this function Timer settings Restore AC This function Power on/...
  • Page 62 15" ATEX Panel PC R15IB3S-65EX User Manual BIOS Setting Description Setting Option Effect Administrator Displays whether Enter Enter password Password or not an administrator password has been set. User Password Display whether Enter Enter password or not a user Password has...
  • Page 63 Chapter 5: BIOS Setup Utility 5.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS use to look for a boot device from which to load the operating system.
  • Page 64 15" ATEX Panel PC R15IB3S-65EX User Manual BIOS Description Setting Effect Setting Option Setup Allows user to configure the Enter Set the prompt Prompt number of seconds to stay in timeout Timeout BIOS setup prompt screen. Boot Enables or disables NumLock...
  • Page 65 Chapter 5: BIOS Setup Utility 5.2.6 Save & Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied.
  • Page 66 15" ATEX Panel PC R15IB3S-65EX User Manual BIOS Description Setting Effect Setting Option Save This saves the changes to the <YES> Save changes Changes CMOS and exits the BIOS Setup and Exit program. Discard This exits the BIOS Setup <YES>...

  • Page 67: Using Recovery Wizard To Restore Computer

    Chapter 5: BIOS Setup Utility 5.3 Using Recovery Wizard to Restore Computer IMPORTANT: Before starting the recovery process, be sure to backup all user data, as all data will be lost after the recovery process. Follow the procedure below to enable quick one-key recovery procedure: ...

  • Page 68: Chapter 6: Technical Support

    15" ATEX Panel PC R15IB3S-65EX User Manual Chapter 6: Technical Support This chapter includes technical support documents and software developing kit (SDK). If any problem occurs fill in problem report form enclosed and immediately contact us.

  • Page 69: Software Developer Support

    Chapter 5: BIOS Setup Utility 6.1 Software Developer Support Download SDK from Winmate Download Center. 6.2 Problem Report Form Stainless Flat Touch Series Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: ________________________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible.

  • Page 70: Appendix

    15" ATEX Panel PC R15IB3S-65EX User Manual Appendix Appendix A: Product Specifications Model Name R15IB3S-65EX Item Specifications System Specifications: Processor Intel® Celeron N2930, 2.16 GHz System Chipset Intel® SoC BIOS AMI BIOS System Memory DDR3L SO-DIMM 1066/1333 MHz, 4GB Default (Up to 8 GB)

  • Page 71: Appendix B: Touchscreen

    Appendix Appendix B: Touchscreen This section includes information on projected capacitive touchscreen (p-cap), its technology and specifications. Overview Projected Capacitive Touch (PCAP) technology is a variant of capacitive touch technology. All PCAP touch screens are made up of a matrix of rows and columns of conductive material, layered on sheets of glass.
