Chapter 1: Before You Begin

Test Leads, Connectors, and Data Ports

For the cable test leads (lower picture), there are two
connectors on the top of the tester (top left).
•
For the battery test cable, there is a 6-pin connector with
a locking ring.
•
For the amp clamp and the multimeter test cables, the
Tester has an accessories port, which is a RJ45 connector
with a release lever.
Top of EXP
Accessories port
connector
Test Leads (optional with EST)
DMM cable with
clamps
Midtronics B.V. Hoofdveste 6 - 8
IR temperature
6-pin
Amp clamp
DMM cable
with probes
Houten NL
IR data
transmitter
sensor
There are two IR data ports on the top of the Tester
(top left).
•
•
The tester also has a DB-9 connector for future
expandability and an SD card slot for future
software upgrades or data logging (top right).
Battery
test cable
6
Bottom of EXP
DB-9
connector for fu-
ture expandability
An IR data transmitter, which transmits test re-
sults to the optional IR printer.
An IR temperature measurement sensor.
EXP-925
SD card slot
for future up-
grades
