Chapter 1: Before You Begin

Data Entry Methods

To perform a particular test or function, the tester will ask for
different types of information. This means that the methods
you use to enter information will change depending on
the type of information requested. The four types of entry
methods are described below.

Menu icons

A menu icon is a graphical representation of a function
you can select, such as the Diode Icon in the DMM Menu.
To select an icon, use the
highlight it. Highlighting changes the icon to a white picture
on a black background. To confirm your selection, press the
appropriate soft key.

Option Buttons

Some lists have option buttons before each item. To select
UP/DOWN ARROW
an item, use the
into the button next to the item you want. You can also use
the alphanumeric keypad to enter the number preceding
the option button. To confirm your selection, press the
appropriate soft key.

Scrolling Lists

Scrolling lists contain items that extend above and below
the screen or the selection box that contains them. To
indicate that there are more items, the symbols
to the right of the first visible or highlighted item on the list.
To select from this type of list, use the
keys to scroll to the item, or use the keypad to enter your
choice, and press the appropriate soft key.

Alphanumeric Entry

Some selections require you to use the alphanumeric
keypad. These "user-defined" selections have a blinking
horizontal line (cursor) to the right of the last character.
UP/DOWN ARROW
Use the
editing. Display the character, symbol, or number you want
by rapidly pressing its key as many times as needed. If you
pause, the cursor moves to the right. To backspace, press the
LEFT ARROW
key. Use the
UP/DOWN ARROW
space. Use the
for editing. When finished, press the appropriate soft key to
save your settings.
Midtronics B.V. Hoofdveste 6 - 8
LEFT RIGHT ARROW
or
keys to move the dot
UP/DOWN ARROW
keys to highlight a line for
RIGHT ARROW
key to add a
keys to highlight a line
Houten NL
key to
appear
8
