Summary of Contents for Kramer WP-5VH2

  • Page 1 PDF provided by Conference Room AV Kramer WP-5VH2 HDMI and VGA w/ Audio Auto Switcher Wall Plate w/ Ethernet, HDBaseT Out...
  • Page 2 K R A ME R E LE CT R O N IC S L TD . PRELIMINARY USER MANUAL MODEL: WP-5VH2 Wall Plate P/N: 2900-300386 Rev 1...

  • Page 5: Table Of Contents

    Analog Audio Output Volume Control Configuring the WP-5VH2 Setting the Configuration DIP-switch Video Switching Timeouts Operating the WP-5VH2 Remotely Using the Embedded Web Pages Browsing the WP-5VH2 Web Pages The Switching Page The Device Settings Page The Video and Audio Settings Page...
  • Page 6 Figures Figure 1: WP-5VH2 and WP-5VH2E Wall Plate Front Panels Figure 2: WP-5VH2 and WP-5VH2E Wall Plate Rear Panels Figure 3: Connecting the WP-5VH2 Wall Plate Figure 4: Remote Switches Terminal Block Figure 5: The Configuration DIP-switch Figure 6: Entering Logon Credentials...

  • Page 7: Introduction

    Display systems requiring simple, automatic input selection  Multimedia and presentation source selection  Video distribution in hotel rooms and schools Note: All mentions of the WP-5VH2 in this User Manual refer also to the WP-5VH2E European version unless otherwise indicated. WP-5VH2 - Introduction...

  • Page 8: Getting Started

    Avoid interference from neighboring electrical appliances that may adversely influence signal quality  Position your Kramer WP-5VH2 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building.

  • Page 9: Shielded Twisted Pair/Unshielded Twisted Pair

    Shielded Twisted Pair/Unshielded Twisted Pair Kramer engineers have developed special twisted pair cables to best match our digital twisted pair products; the Kramer BC-HDKat6a (CAT 6 23 AWG) HDBaseT certified, and the Kramer BC-DGKat7a23 (CAT 7a 23 AWG) cables. These specially built cables significantly outperform regular CAT 6 and CAT 7a cables.

  • Page 10: Overview

    HDBaseT (Twisted Pair) cable to a compatible receiver (for example, the TP-588D or the TP-580RXR). The WP-5VH2 is a PoE (Power over Ethernet) receiver and can be powered by a compatible PoE provider, (for example, the PSE-1).

  • Page 11: About Hdbaset™ Technology

     HDCP compliancy—works with sources that support HDCP repeater mode  I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID handling & processing algorithm ensures Plug and Play operation for HDMI systems  A lockable EDID  Remote control via contact-closure switches ...

  • Page 12: Defining The Wp-5Vh2 Wall Plate

    Defining the WP-5VH2 Wall Plate Figure 1 defines the front panels of the WP-5VH2 and WP-5VH2E. Figure 1: WP-5VH2 and WP-5VH2E Wall Plate Front Panels...
  • Page 13 Connect to the LAN, (Ethernet traffic or PC controller) AUDIO IN 3.5mm Mini Jack Connect to the unbalanced, stereo audio source, (for example, the audio output of the laptop) Figure 2 defines the rear panels of the WP-5VH2 and the WP-5VH2E.

  • Page 14: Figure 2: Wp-5Vh2 And Wp-5Vh2E Wall Plate Rear Panels

    Figure 2: WP-5VH2 and WP-5VH2E Wall Plate Rear Panels...
  • Page 15 REMOTE 5-pin Terminal Block, Connect to the remote, contact-closure switches for remote control, (see Section 5.1) (only on the WP-5VH2) AUDIO OUT 3-pin Terminal Block Connect to the unbalanced, stereo audio acceptor, (for example, an audio amplifier) HDBT OUT RJ-45 TP Connector...

  • Page 16: Connecting The Wp-5Vh2

    Connecting the WP-5VH2 Switch off the power to all devices before connecting them to your WP-5VH2. After connecting your WP-5VH2 connect the power to other devices. Figure 3: Connecting the WP-5VH2 Wall Plate Figure To connect the WP-5VH2 as illustrated in 1.

  • Page 17: Connecting The Remote Control Switches

    Note: Only applicable to the WP-5VH2. You can connect remote, momentary-contact contact-closure switches to the terminal block on the rear panel of the WP-5VH2 to control the device. Figure 4 illustrates the connections from the terminal block to the contact-closure switches.
  • Page 18 Analog audio output volume Short press—Decreases the volume one step decrease control, (see Long press—Decreases the volume from 100% to 0% Section 7.4) in 10 seconds Ground Connect to the common side of the switches WP-5VH2 - Connecting the WP-5VH2...

  • Page 19: Principles Of Operation

    In auto mode, switching selection can be based on either last connected or priority inputs. In last connected mode the WP-5VH2 selects the input based on which input was connected last. If the signal on this input is subsequently lost for any reason, the input with a live signal and which was also the last connected is selected automatically.

  • Page 20: Audio Signal Control

    1 and G pins of the Remote terminal block. Each long press steps the phase shift up one step, starting from 0 and going to 31. When set to 31, another long press steps the shift to 0. WP-5VH2 - Principles of Operation...

  • Page 21: Operating The Wp-5Vh2

    Operating the WP-5VH2 Powering up the WP-5VH2 recalls the last settings from the non-volatile memory, (that is, the configuration of the device when it was powered down). Selecting an Input Manually Any of the following methods can be used to select an input: ...
  • Page 22 Ramp Volume (%) Volume (dB) –0.5 –1.0 –1.5 –2.0 … (0.5 steps) –44.0 –44.5 –45.0 –45.5 … (2.0 steps) –47.0 –49.0 –51.0 –53.0 –55.0 –57.0 –59.0 –61.0 –63.0 WP-5VH2 - Operating the WP-5VH2...

  • Page 23: Configuring The Wp-5Vh2

    When two sources are connected the Manual video input selection Connected last one connected gets priority When two sources are connected the On—Priority Manual video input selection active source is selected according to the pre-defined priority WP-5VH2 - Configuring the WP-5VH2...

  • Page 24: Video Switching Timeouts

    Video Switching Timeouts When the WP-5VH2 is configured for auto switching, the timeouts before a new input is automatically selected can be changed as shown in the table below. New Signal Signal Loss, Signal and Power Detected Power Present Loss...

  • Page 25: Operating The Wp-5Vh2 Remotely Using The Embedded Web Pages

    Operating the WP-5VH2 Remotely Using the Embedded Web Pages The WP-5VH2 can be operated remotely using the embedded Web pages. The Web pages are accessed using a Web browser and an Ethernet connection. Before attempting to connect:  Ensure that your browser is supported (see Section ...

  • Page 26: Figure 7: The Default Page

    Click to reveal the left hand side page panel Hide/Reveal Button Click the Reveal button to open the left hand side page panel. The Switching page appears as shown in Figure WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...

  • Page 27: Figure 8: The Main Switching Page

    Audio Volume Controls Use the slider and mute button to control the audio volume Audio Selection Indication Indicates the source of the audio that is currently on the output WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...
  • Page 28 2. Do either of the following:  Click Download to either open the file or save it to the required location —OR—  Click OK to complete the procedure WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...

  • Page 29: The Switching Page

    The Device Settings page lets you:  View some of the device characteristics, (for example, model and Web version)  Edit IP settings, (for example, name and IP address)  Upgrade the firmware WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...

  • Page 30: Figure 10: The Device Settings Page

    Set Gateway The network gateway for the device. To set a new network gateway, enter the new valid gateway and click Set WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...
  • Page 31 The firmware file name is displayed in the Firmware Upgrade page. 4. Click Start Upgrade. The firmware file is loaded and a progress bar is displayed. Do not interrupt the process or the WP-5VH2 may be damaged. 5. When the process is complete reboot the device. The firmware is upgraded.

  • Page 32: The Video And Audio Settings Page

    Click either the HDMI or VGA buttons to select the priority Buttons priority selection when in auto mode Audio selection mode Indicates the current audio selection; manual, auto, or Indicator auto last connected WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...

  • Page 33: The Authentication Page

    Figure 12: The Authentication Page Item Description Activate Security Button Click to enable/disable security settings. When enabled, the valid username and password must be provided to allow Web page access WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...

  • Page 34: The Edid Page

     Output  Input  Default EDID  EDID data file From this page you can also lock the EDID on each input independently. Figure 13: The EDID Page WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...
  • Page 35 EDID data. 3. Click the Copy button. The “EDID was copied” success message is displayed and the EDID data is copied to the selected input(s). 4. Click OK. WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...

  • Page 36: The About Us Page

    The About Us Page The WP-5VH2 About Us page displays the Web page version and Kramer Electronics Ltd company details. Figure 14: The About Us Page WP-5VH2 - Operating the WP-5VH2 Remotely Using the Embedded Web Pages...

  • Page 37: Wiring The Twisted Pair Rj-45 Connectors

    Brown Pair 1 4 and 5 Pair 2 1 and 2 Pair 3 3 and 6 Using a TP cable that is incorrectly wired will cause Warning: permanent damage to the device WP-5VH2 - Wiring the Twisted Pair RJ-45 Connectors...

  • Page 38: Technical Specifications

    9.0cm x 4.9 cm x 10.6cm (3.54” x 1.93” x 4.17”) W, D, H WEIGHT: 0.39kg (0.86lbs) approx. SHIPPING WEIGHT: 0.68kg (1.5lbs) approx. ENVIRONMENTAL Complies with appropriate requirements of RoHs and WEEE REGULATORY COMPLIANCE: INCLUDED ACCESSORIES: Power adapter WP-5VH2 - Technical Specifications...

  • Page 39: Default Ip Parameters

    720x480p 60Hz 720x480i 30Hz 720x576p 50Hz 800x600p 85Hz; 75Hz; 72Hz; 60Hz 848x480p 60Hz 852x480p 60Hz 1024x768p 85Hz; 75Hz; 70Hz; 60Hz 1152x864p 75Hz 1280x768p 60Hz 1280x800p 60Hz 1280x960 60Hz 1280x1024p 75Hz; 60Hz 1360x768p 60Hz 1366x768 60Hz; 50Hz WP-5VH2 - Technical Specifications...
  • Page 40 60Hz 720x480p 60Hz 800x600p 60Hz 848x480p 60Hz 1024x768p 60Hz 1152x864 75Hz 1280x720p 60Hz; 50Hz 1280x768 60Hz 1280x800 60Hz 1280x960p 60Hz 1280x1024p 60Hz 1360x768 60Hz; 1366x768 60Hz; 50Hz 1400x1050 60Hz 1440x900 60Hz 1920x1080p 60Hz 1920x1200 60Hz; 50Hz WP-5VH2 - Technical Specifications...

  • Page 41: Default Edid

    Default EDID Each input on the WP-5VH2 is loaded with a factory default EDID. 12.1 HDMI Monitor Model name....WP-5VH2 Manufacturer..... KMR Plug and Play ID..KMR1200 Serial number.... 505-803050100 Manufacture date..2014, ISO week 255 Filter driver.... None ------------------------- EDID revision....
  • Page 42 Front left/right center.. No Rear left/right center... No Rear LFE....No Report information Date generated... 31/12/2014 Software revision..2.60.0.972 Data source....File Operating system..6.1.7601.2.Service Pack 1 Raw data 00,FF,FF,FF,FF,FF,FF,00,2D,B2,00,12,01,01,01,01,FF,18,01,04,80,34,20,78,EA,B3,25,AC,51,30,B4,26, 10,50,54,FF,FF,80,81,8F,81,99,A9,40,61,59,45,59,31,59,71,4A,81,40,01,1D,00,72,51,D0,1E,20,6E,28, 55,00,07,44,21,00,00,1E,00,00,00,FF,00,35,30,35,2D,38,30,33,30,35,30,31,30,30,00,00,00,FC,00,57, 50,2D,35,56,48,32,00,00,00,00,00,00,00,00,00,FD,00,38,4C,1E,53,11,00,0A,20,20,20,20,20,20,01,AF, 02,03,1B,F1,23,09,07,07,48,10,05,84,03,02,07,16,01,65,03,0C,00,10,00,83,01,00,00,02,3A,80,18,71, 38,2D,40,58,2C,45,00,07,44,21,00,00,1E,01,1D,80,18,71,1C,16,20,58,2C,25,00,07,44,21,00,00,9E,01, 1D,00,72,51,D0,1E,20,6E,28,55,00,07,44,21,00,00,1E,8C,0A,D0,8A,20,E0,2D,10,10,3E,96,00,07,44,21, 00,00,18,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,47 WP-5VH2 - Default EDID...

  • Page 43: Pc-Uxga

    800 x 600p at 85Hz - VESA STD 640 x 480p at 85Hz - VESA STD 1152 x 864p at 70Hz - VESA STD 1280 x 960p at 60Hz - VESA STD EIA/CEA-861 Information Revision number..3 IT underscan..... Supported Basic audio....Supported WP-5VH2 - Default EDID...
  • Page 44 Front left/right center.. No Rear left/right center... No Rear LFE....No Report information Date generated... 31/12/2014 Software revision..2.60.0.972 Data source....File Operating system..6.1.7601.2.Service Pack 1 Raw data 00,FF,FF,FF,FF,FF,FF,00,2D,B2,00,12,01,01,01,01,FF,18,01,04,6E,34,20,78,EE,B3,25,AC,51,30,B4,26, 10,50,54,FF,FF,80,81,8F,81,99,A9,40,61,59,45,59,31,59,71,4A,81,40,01,1D,00,72,51,D0,1E,20,6E,28, 55,00,07,44,21,00,00,1E,00,00,00,FF,00,35,30,35,2D,38,30,33,30,35,30,31,30,30,00,00,00,FC,00,57, 50,2D,35,56,48,32,00,00,00,00,00,00,00,00,00,FD,00,38,4C,1E,53,11,00,0A,20,20,20,20,20,20,00,BE, 02,03,1B,F1,23,09,07,07,48,10,05,84,03,02,07,16,01,65,03,0C,00,10,00,83,01,00,00,02,3A,80,18,71, 38,2D,40,58,2C,45,00,07,44,21,00,00,1E,01,1D,80,18,71,1C,16,20,58,2C,25,00,07,44,21,00,00,9E,01, 1D,00,72,51,D0,1E,20,6E,28,55,00,07,44,21,00,00,1E,8C,0A,D0,8A,20,E0,2D,10,10,3E,96,00,07,44,21, 00,00,18,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,00,47 WP-5VH2 - Default EDID...

  • Page 45: Protocol 3000

    Protocol 3000 The WP-5VH2 can be operated using serial commands from a PC, remote controller or touch screen using the Kramer Protocol 3000. This section describes:  Kramer Protocol 3000 syntax (see Section 13.1)  Kramer Protocol 3000 commands (see Section 13.2)
  • Page 46 CRLF – For device messages; carriage return (ASCII 13) + line-feed (ASCII 10) Command chain separator character When a message string contains more than one command, a pipe ( '|' ) character separates each command. Spaces between parameters or command terms are ignored. WP-5VH2 - Protocol 3000...
  • Page 47 You can directly enter all commands using a terminal with ASCII communications software, such as HyperTerminal, Hercules, etc. Connect the terminal to the serial or Ethernet port on the Kramer device. To enter CR press the Enter key. ( LF is also sent but is ignored by command parser).

  • Page 48: Kramer Protocol 3000 Commands

    For a full description of the commands, see the Kramer Protocol 3000 document available from http://www.kramerelectronics.com. Note: The WP-5VH2 can only receive commands from a device, (for example, an HDBT transmitter) via the HDBaseT link, and only at 9600bps. Command...
  • Page 49 Get device protocol version RESET Reset device ROUTE Set/get layer routing SECUR Start/Stop Security SIGNAL? Get input signal lock status Read device serial number UPGRADE Execute firmware upgrade VERSION? Read device firmware version VMUTE Set/get video on output mute WP-5VH2 - Protocol 3000...
  • Page 50 Command Type - System-mandatory Command Name Permission Transparency Set: End User Public Get: Description Syntax Set: Protocol handshaking #␍ Get: Response ~nn@␠OK␍␊ Parameters Response Triggers Notes Use to validate the Protocol 3000 connection and get the machine number WP-5VH2 - Protocol 3000...
  • Page 51 Response is sent to the com port from which the Set (before execution)/Get command was received After execution, response is sent to all com ports if AUD-EMB was set by any other external control device (button press, device menu and similar) Notes WP-5VH2 - Protocol 3000...
  • Page 52 - ‘IN, ’OUT’ or numeric value of present audio processing stage For example: ‘1’ for input level, ‘2’ for output channel - input or output number volume - audio parameter in Kramer units, minus sign precedes negative values. ++ increase current value, -- decrease current value...
  • Page 53 1 - ON (signal present Response Triggers After execution, response is sent to the com port from which the Get was received Response is sent to all com ports if audio status state was changed on any input Notes WP-5VH2 - Protocol 3000...
  • Page 54 Get input auto switch mode (per output) # AV-SW-MODE?␠layer,output_id␍ Response ~ nn@AV-SW-MODE␠layer,output_id, mode␍␊ Parameters layer output_id - 1….num of system outputs mode - 0 - manual 1 - priority switch 2 - last connected switch Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 55 - 0 - on video signal loss timeout 1 - on new video signal detected switch timeout 2 - on audio signal loss timeout 3 - on audio signal detected switch timeout timeout - timeout in seconds Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 56 Get device build date #BUILD-DATE␍ Response ~nn@BUILD-DATE␠date␠time␍␊ Parameters date - Format: YYYY/MM/DD where YYYY = Year, MM = Month, DD = Day time - Format: hh:mm:ss where hh = hours, mm = minutes, ss = seconds Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 57 Response is sent to the com port from which the Set was received (before execution) Notes Destination bitmap size depends on device properties (for 64 inputs it is a 64-bit word) Example: bitmap 0x0013 means inputs 1,2 and 5 are loaded with the new EDID WP-5VH2 - Protocol 3000...
  • Page 58 Command Type - File System Command Name Permission Transparency Set: Administrator Public Get: Description Syntax Set: Delete file #DEL␠file_name␍ Get: Response ~nn@DEL␠file_name␠OK ␍␊ Parameters file_name - name of file to delete (file names are case-sensitive) Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 59 - file size in bytes. A file can take more space on device memory file_id - internal ID for file in file system free_size - free space in bytes in device file system Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 60 Response is sent after every change in output HPD status ON to OFF Response is sent after every change in output HPD status OFF to ON and ALL parameters (new EDID, etc.) are stable and valid Notes WP-5VH2 - Protocol 3000...
  • Page 61 Get Ethernet port protocol #ETH-PORT?␠portType␠portNum␍ Response ~nn@ ETH-PORT␠portType, ETHPort, portNum␍␊ Parameters portNum - 1-N TCP/UDP port enumerator (equals the connected com port number from the tunneling port) portType - TCP/UDP ETHPort - TCP/UDP port number Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 62 End User Public FACTORY Get: Description Syntax Reset device to factory default Set: #FACTORY␍ configuration Get: Response ~nn@FACTORY␠OK␍␊ Parameters Response Triggers Notes This command deletes all user data from the device. The deletion can take some time. WP-5VH2 - Protocol 3000...
  • Page 63 Command Name Permission Transparency Set: Factory Internal FCT-MAC Get: Description Syntax Set: Set MAC address #FCT-MAC␠mac_address␍ Get: Response ~nn@FCT-MAC␠mac_address␠OK␍␊ Parameters mac_address - Unique MAC address. Format: XX-XX-XX-XX-XX-XX where X is a hex digit Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 64 - String of printable ASCII chars (up to 19 chars) Response Triggers Notes Used where a single firmware file is adaptable for many devices, but the user needs to know (by protocol) which specific model is used WP-5VH2 - Protocol 3000...
  • Page 65 Internal FCT-SN Get: Description Syntax Set: Set serial number #FCT-SN␠serial_number␍ Get: Response ~nn@FCT-SN␠serial_number␠OK␍␊ Parameters serial_number - 11 decimal digits Response Triggers Notes For new products with 14 digit serial numbers, use only the last 11 digits WP-5VH2 - Protocol 3000...
  • Page 66 Command Type - File System FORMAT Command Name Permission Transparency Set: Administrator Public FORMAT Get: Description Syntax Set: Format file system #FORMAT␍ Get: Response ~nn@FORMAT␠OK␍␊ Parameters Response Triggers Notes Response could take some time (seconds) until formatting completes WP-5VH2 - Protocol 3000...
  • Page 67 Public FPGA-VER? Description Syntax Set: Get: Get current FPGA version #FPGA-VER?␠id␍ Response ~nn@FPGA-VER␠id, expected_ver, actual_ver␍␊ Parameters id - FPGA id expected_ver - expected FPGA version for current firmware actual_ver - actual FPGA version Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 68 FS-FREE? Command Name Permission Transparency Set: Get: Administrator Public FS-FREE? Description Syntax Set: Get: Get file system free space #FS-FREE?␍ Response ~nn@FS_FREE␠free_size␍␊ Parameters free_size - free size in device file system in bytes Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 69 Response is sent to the com port from which the Set (before execution) / Get command was received Notes For Get, size=0 means EDID is not supported For old devices that do not support this command, ~nn@ ERR 002␍␊ is received WP-5VH2 - Protocol 3000...
  • Page 70 - name of file to get contents contents - byte stream of file contents file_size - size of file (device sends it in response to give user a chance to get ready) Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 71 (button press, device menu and similar) or HDCP mode changed Notes Set HDCP working mode on the device input: HDCP supported - HDCP_ON [default] HDCP not supported - HDCP OFF HDCP support changes following detected sink - MIRROR OUTPUT WP-5VH2 - Protocol 3000...
  • Page 72 Response is sent to the com port from which the Set (before execution) / Get command was received Response is sent to all com ports after execution if HDCP-STAT was set by any other external control device (button press, device menu and similar) or HDCP mode changed Notes WP-5VH2 - Protocol 3000...
  • Page 73 Get command list or help for specific 1. #HELP␍ Get: command 2. #HELP␠command_name␍ Response 1. Multi-line: ~nn@Device available protocol 3000 commands:␍␊command,␠command…␍␊ To get help for command use: HELP (COMMAND_NAME)␍␊ 2. Multi-line: ~nn@HELP␠command:␍␊description␍␊USAGE:usage ␍␊ Parameters Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 74 ~nn@LDEDID␠ERR01␍␊ and returns to the regular protocol mode. If the unit received data that is not a correct packet, it sends the corresponding error and returns to the regular protocol mode. WP-5VH2 - Protocol 3000...
  • Page 75 FIRMWARE_DATA - HEX or KFW file in protocol packets (see Section Response Triggers Notes In most devices firmware data is saved to flash memory, but the memory does not update until receiving the “UPGRADE” command and is restarted. Use this command in dedicated SW application WP-5VH2 - Protocol 3000...
  • Page 76 * End User (+Device)- Send file in Protocol Packets * Device - ~01@LOAD␠file_name, size␠OK␍␊ Parameters file_name - name of file to save on device size - size of file data that is sent. Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 77 Get EDID lock state #LOCK-EDID? ␠ input_id ␍ Response ~ nn @LOCK-EDID ␠ input_id,lock_mode ␍␊ Parameters st onofm m sn sufo mun.… ni_tupni Os1 o I unOs 1 o I E s 1/ n ecompkcil Response triggers Notes WP-5VH2 - Protocol 3000...
  • Page 78 In each device, some connections can be logged in to different levels and some do not work with security at all Connection may logout after timeout The permission system works only if security is enabled with the “SECUR” command WP-5VH2 - Protocol 3000...
  • Page 79 Command Name Permission Transparency Set: Not Secure Public LOGOUT Get: Description Syntax Set: Cancel current permission level #LOGOUT␍ Get: Response ~nn@LOGOUT␠OK␍␊ Parameters Response Triggers Notes Logs out from End User or Administrator permission levels to Not Secure WP-5VH2 - Protocol 3000...
  • Page 80 Command Type - System-mandatory MODEL? Command Name Permission Transparency Set: Get: End User Public MODEL? Description Syntax Set: Get: Get device model #MODEL?␍ Response ~nn@MODEL␠model_name␍␊ Parameters model_name - String of up to 19 printable ASCII chars Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 81 End User Public MUTE? Description Syntax Set: Set audio mute #MUTE␠channel,mute_mode␍ Get: Get audio mute #MUTE?␠channel␍ Response ~nn@MUTE␠channel, mute_mode␍␊ Parameters channel - output number mute_mode - 0 or OFF / 1 or ON Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 82 - String of up to 14 alpha-numeric chars (can include hyphen, not at the beginning or end) Response Triggers Notes The machine name is not the same as the model name. The machine name is used to identify a specific machine or a network in use (with DNS feature on) WP-5VH2 - Protocol 3000...
  • Page 83 NAME-RST Get: Description Syntax Reset machine (DNS) name to Set: #NAME-RST␍ factory default Get: Response ~nn@NAME-RST␠OK␍␊ Parameters Response Triggers Notes Factory default of machine (DNS) name is “KRAMER_” + 4 last digits of device serial number WP-5VH2 - Protocol 3000...
  • Page 84 To connect with a randomly assigned IP by DHCP, specify the device DNS name (if available) using the command “NAME”. You can also get an assigned IP by direct connection to USB or RS-232 protocol port if available For proper settings consult your network administrator WP-5VH2 - Protocol 3000...
  • Page 85 Get: ~nn@NET-GATE␠ip_address␍␊ Parameters ip_address - format: xxx.xxx.xxx.xxx Response Triggers Notes A network gateway connects the device via another network and maybe over the Internet. Be careful of security problems. For proper settings consult your network administrator WP-5VH2 - Protocol 3000...
  • Page 86 Public NET-IP? Description Syntax Set: Set IP address #NET-IP␠ip_address␍ Get: Get IP address #NET-IP?␍ Response Set: ~nn@ NET-IP␠ip_address␠OK␍␊ Get: ~nn@ NET-IP␠ip_address␍␊ Parameters ip_address - format: xxx.xxx.xxx.xxx Response Triggers Notes For proper settings consult your network administrator WP-5VH2 - Protocol 3000...
  • Page 87 Command Name Permission Transparency Set: Get: End User Public NET-MAC? Description Syntax Set: Get: Get MAC address #NET-MAC?␍ Response ~nn@NET-MAC␠mac_address␍␊ Parameters mac_address - Unique MAC address. Format: XX-XX-XX-XX-XX-XX where X is hex digit Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 88 Get: Get subnet mask #NET-MASK?␍ Response Set: ~nn@NET-MASK␠net_mask␠OK␍␊ Get: ~nn@NET-MASK␠net_mask␍␊ Parameters net_mask - format: xxx.xxx.xxx.xxx Response Triggers The subnet mask limits the Ethernet connection within the local network For proper settings consult your network administrator Notes WP-5VH2 - Protocol 3000...
  • Page 89 ~nn@PASS␠login_level, password␠OK ␍␊ Parameters login_level - level of login to set (End User or Administrator). password - password for the login_level. Up to 15 printable ASCII chars Response Triggers Notes The default password is an empty string WP-5VH2 - Protocol 3000...
  • Page 90 Get input priority # PRIORITY?layer ␍ Response PRIORITY␠layer,PRIORITY1, PRIORITY2… PRIORITYn ␍␊ ~ nn@ Parameters layer PRIORITY1 - priority of first input PRIORITYn- priority of input n Response Triggers Notes WP-577VH – layer parameter is not used WP-5VH2 - Protocol 3000...
  • Page 91 Command Type - System-mandatory PROT-VER? Command Name Permission Transparency Set: Get: End User Public PROT-VER? Description Syntax Set: Get: Get device protocol version #PROT-VER?␍ Response ~nn@PROT-VER␠3000:version␍␊ Parameters Version - XX.XX where X is a decimal digit Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 92 Response Triggers Notes To avoid locking the port due to a USB bug in Windows, disconnect USB connections immediately after running this command. If the port was locked, disconnect and reconnect the cable to reopen the port. WP-5VH2 - Protocol 3000...
  • Page 93 #ROUTE?␠layer, dest␍ Response ROUTE␠ layer, dest, src ␍␊ ~ nn@ Parameters layer dest - * - ALL x - disconnect, otherwise destination id src - source id Response Triggers Notes This command replaces all other routing commands. WP-5VH2 - Protocol 3000...
  • Page 94 Get current security state #SECUR?␍ Response Set: ~nn@SECUR␠security_mode␠OK ␍␊ Get: ~nn@SECUR␠security_mode ␍␊ Parameters security_mode – 1/ON - enables security, 0/OFF - disables security Response Triggers Notes The permission system works only if security is enabled with the “SECUR” command WP-5VH2 - Protocol 3000...
  • Page 95 Response Triggers After execution, a response is sent to the com port from which the Get was received Response is sent after every change in input signal status ON to OFF, or OFF to ON Notes WP-5VH2 - Protocol 3000...
  • Page 96 Description Syntax Set: Get: Get device serial number #SN?␍ Response ~nn@SN␠serial_number␍␊ Parameters serial_number - 11 decimal digits, factory assigned Response Triggers Notes For new products with 14 digit serial numbers, use only the last 11 digits WP-5VH2 - Protocol 3000...
  • Page 97 Syntax Set: Perform firmware upgrade #UPGRADE␍ Get: Response ~nn@UPGRADE␠OK␍␊ Parameters Response Triggers Notes Not necessary for some devices Firmware usually uploads to a device via a command like LDFW Reset the device to complete the process WP-5VH2 - Protocol 3000...
  • Page 98 VERSION? Command Name Permission Transparency Set: Get: End User Public VERSION? Description Syntax Set: Get: Get firmware version number #VERSION?␍ Response ~nn@VERSION␠firmware_version␍␊ Parameters firmware_version - XX.XX.XXXX where the digit groups are: major.minor.build version Response Triggers Notes WP-5VH2 - Protocol 3000...
  • Page 99 2 - blank video Response Triggers Notes 13.2.1 EDID Source Number Value Input Output Default EDID 13.2.2 Signal Validation Number Value Signal or sink is not valid Signal or sink is valid Sink and EDID is valid WP-5VH2 - Protocol 3000...
