Scan for full manual
Step 1: Check what's in the box
WP-20CT
HDMI 4K Wall-Plate Line Transmitter
+12V Power adapter (with open DC head) and cord
#
Feature
HDMI™ IN Connector
1
2
USB-C LED
HDMI LED
3
STATUS LED
4
USB-C IN Port
WP-20CT Quick Start
WP-20CT Quick Start Guide
This guide helps you install and use your
Go to
www.kramerav.com/downloads/WP-20CT
upgrades are available.
Function
Connects to an HDMI source.
Off – when an input source is not connected.
Blue – when an active signal is detected on the input.
Blue, flashing – when the source is connected but an active signal is not detected.
Off – the device does not receive power.
Red – the powered device is inactive or booting.
Green – the device is active and powered via power supply.
Orange – the device is active and powered via PoE.
Green or orange (depending on power source), flashing slowly – the device is in
the power-save standby mode.
Green or orange (depending on power source), fast-flashing – firmware is
downloaded in the background.
Connect to a USB-C source (that supports DisplayPort Alternate Mode).
When powered by a Kramer 20V power supply (optional), charges sources (that
support USB Power Delivery 2.0) up to 60W.
Use to access
WP-20CT
for the first time.
to download the latest user manual and check if firmware
1 Quick start guide
Frame (or frame set) and faceplate
WP-20CT
internal web pages via connected browser.
P/N: 2 9 0 0 - 3 0 1 4 7 6 QS
Installation accessories
Rev: 1
Advertisement
Table of Contents
Related Manuals for Kramer WP-20CT
Summary of Contents for Kramer WP-20CT
- Page 1 USB-C IN Port Connect to a USB-C source (that supports DisplayPort Alternate Mode). When powered by a Kramer 20V power supply (optional), charges sources (that support USB Power Delivery 2.0) up to 60W. Use to access WP-20CT internal web pages via connected browser.
- Page 2 Connect to the power supply (required for USB charging). Connect GND to GND, Terminal Block Connector +12V/20V to +12/20V. If you need to charge a device via the USB-C port, use Kramer 20V power supply (optional). HDBT OUT PoE RJ-45 Connector Connect to the HDBT IN port on a PoE-provider receiver (for example, TP-789R) or a receiver (for example, TP-580R).
- Page 3 Step 3: Connect the inputs and outputs Always switch OFF the power on each device before connecting it to your WP-20CT. For best results, we recommend that you always use Kramer high-performance cables to connect AV equipment to the WP-20CT.
- Page 4 • Do not open the unit. High voltages can cause electrical shock! Servicing by qualified personnel only. • To ensure continuous risk protection, replace fuses only according to the rating specified on the product label which located on the bottom of the unit. Step 5: Operating WP-20CT Control and operate WP-20CT •...
