PRESTO
GmbH & Co. KG
Bad Laer
Pos.
Designation / Type
14.1
Pawl
CC 13, CC 20, CC 30
CC 40
(2x)
14.2
Leaf spring
15.1
Deflection wheel z16
15.2
Bearing
15.3
"Seeger" circlip ring
16.1
Deflection pinion z = 11
16.2
Bearing
16.3
"Seeger" circlip ring
Illustration
(2x)
14.1
(2x)
14.2
04/2012
10 - 5
Item no.
100056802
100120702
100088101
100039800
253001008
601300004
100039700
253001008
601300004
