PRESTO
GmbH & Co. KG
Bad Laer
4
Retract needle to operating position. Pressing ram is retracted (rear). Press and hold the
Needle up button (4a). Needle moves up and stops in the
Inserting the upper wire
a) Pull the wire through the wire deflection pulley as shown below. Push the wire as far
as possible through the opening in the press shaft
b) Close all doors/covers
c) Select Automatic operating mode (8)
d) Press Operation button (9).
e) Perform approximately 2 – 3 press operations with the material until the upper wire
is tight.
f) During the subsequent extension of the pressing ram, rotate the bale length wheel
(B30) until Binding is indicated on the Touch panel (or if existent the light signal
Binding flashes).
3
Bale length
wheel
04/2012
2
Operating position
6 - 17
1
(B34 + B35).
Binding signal
