• Switch box (1) with relay (2) motor
protection switch (3), fuses (4) and
operating elements, stored program
control (5) and wiring,
• Limit switch, press in front (B33)
• Limit switch, press backwards (B31)
See fig. "Overview limit switches", page 5-8
04/2012 5 - 7
B33
B31
