Possible error messages:
No.: Message:
8000 fail of proxy, ram, rear position
(B31)
8001 fail of proxy, ram, front position
(B32)
8002 fail of proxy, ram, front position
(B33)
8003 fail of proxy, needle down (B34)
8004 fail of proxy, needle down (B35)
8005 fail of proxy, needle on top (B36)
8006 fail at valve channel relief
8011 fail at oil level or oil temperature
(B1)
8012 fail at valve channel pressure
8013 needle is not in operating
position
8014 twister not in operating position
8015 fail at motor protection (Q2)
8016 fail at sensor ram pressure (B2)
8017 fail at sensor channel pressure
(B3)
8024 error, wire left-hand
8025 error, wire middle-left
8026 error, wire middle-right
This error message appears if:
The proximity switches „ ram in rear position " (B31) and „ ram in front " (B33)
are activated and the proximity switch „ ram in front " (B32) is not activated.
This error message appears if:
The valves „ram forward " and "bypass" are activated, and the limit switch
„ram in front position" (B32) turns on.
This error message appears if:
The valves „ ram forward " and "bypass" are activated, the proximity switch „
ram in front " (B32) is activated, and the proximity switch „ ram in front " (B33)
is switched on.
If the proxy switch „ needle down in operating position " (B35) and the proxy
switch „needle up" (B36) are activated at the same time and the proxy switch „
needle down in threading position" (B34) is not activated, this message
appears.
If the proxy switch „ needle down in operating position " (B35) is activated and
the proxy switch „ needle down in threading position " (B34) is not activated,
this message appears.
This error message appears if:
The proximity switches „ needle down in operating position " (B35), „ needle
down in threading position " (B34) and „ needle on top " (B36) are activated at
the same time.
This error message appears if:
The maximum pressure at the channel is reached, and the valve „channel
pressure relief " does not relief.
This error message appears if:
The switch "oil level or oil temperature monitoring" is activated.
Oil loss in the system or is too hot (>90°C)!
If the valve "canal pressure built-up" is activated for more than 5 seconds in
automatic mode without interruption, this message appears.
If the plant is activated in Auto mode and no "binding signal" lines up and
either the proximity switch „needle down in operating position "(B35) or the
proximity switch „needle down in threading position"(B34) is not activated,
this message appears.
This error message appears if:
The proximity switch 'twister' (B37) does not switch in Auto mode without
'binding' signal.
This error message appears if:
Motor protection relays of the pump or if available conveyor belt,
Fluffer etc. is tripped.
! Reset motor protection relays. Push the button "reset" to acknowledge!
This error message appears if:
The pressure sensor "ram pressure" (B2) is defective.
Check the plug at pressure sensor!
This error message appears if:
The pressure sensor "canal pressure" (B3) is defective.
Check the plug at pressure sensor!
This error message appears if:
The binding wire on the left is ripped or missing or the proximity switch
"binding wire on the left" is defective.
This error message appears if:
The binding wire on the middle left is ripped or missing or the proximity switch
"binding wire on the middle left" is defective.
This error message appears if:
The binding wire on the middle right is ripped or missing or the proximity
switch "binding wire on the middle right" is defective.
04/2012
Reason:
