Note:
Always use binding wire with the a.m.
properties. Binding wire that does not
correspond to the specification may lead to
trouble in the work sequence. You will find
the part numbers in chapter 10, spare parts.
• Throw the material into the charging
funnel. Fill the shaft up to slightly above
the counter knife.
Make sure that no pressing strokes are
effected if the filled in material is not slightly
above the counter knife.
• Check whether there is sufficient binding
wire on the coils.
• Put operation mode selector in "Auto"
position.
• Switch on main switch, press "Operation"
key. The flashing of the control lamp
indicates the readiness for operation of
the unit.
• Press "Start" key (4). The unit starts up
and starts compressing.
• If the funnel has been filled up with
sufficient material and the compressing
die is in its end position, the machine
starts automatically via the installed light
barrier.
The unit will check after the start
whether the compressing die is in the
rear position. The compressing die returns to
the back limit position and the pump is
switched off.
• The length of the bale permanently
increases. It is continuously collected by
the pulse generator and indicated.
6.4.1 Operation mode "Manual"
General
• Switch on main switch, press button
operation, light "operation" is lighting.
• Put operation mode selector switch into
"Manual" position
• Press "Start" Button, the hydraulic pump
starts up.
• Move selector switch "Press
forward/back" into desired direction and
keep as long as the press is to be moved.
04/2012 6 - 5
The manual operation modes
described in the following
assume that the operation
mode selector switch is put in
"Manual" position. The
operation mode "Manual"
has to be used for the
threading of a new binding
wire and for maintenance,
repair and adjustment works.
