The station is controlled via a WiCo. If the WiCo is
mounted on the station, data is exchanged between the
station and WiCo via the contacts (C). The screen of the
WiCo displays the home icon .
The WiCo is equipped with a USB socket (Universal Serial
Bus) with which the WiCo can be connected with station,
the USB icon appears on the screen.
If the WiCo is not connected with station via a USB
cable, the data exchange between the station and the
WiCo via Bluetooth ® . In this case, the Bluetooth
is displayed .

• Working screen at the time of delivery:

0.00
int 5.00
Fig. 21
Note: The wireless symbol
station is switched on.

• Explanation of symbols on the working screen:

The symbols displayed change depending on the status
and settings of the WiCo and the station. The screen
below shows the most significant symbols on the work-
ing screen.
99
10.00
10.00
int 10.00
Fig. 22

Useful information

Working with WiCo

A
int °C
ext °C
1000
set °C Pump rpm
appears only when the
A
int °C
PC
ext °C
1000
set °C Pump rpm
Depending on the structure of the building, the WiCo can
be operated at a distance up to 15 m from the station,
using the Bluetooth
The WiCo could be either installed on the station or put
on a safe place where is accessed easily by the user during
operation.
If the WiCo is mounted on the station, the battery is
charged through the contacts (C).
The battery could also be charged via the USB port on the
® icon WiCo (See "Charging the Battery Pack RB 1" in "Prepara-
tions" section).
Bluetooth
This symbol means the
municating via Bluetooth
The symbol no longer appears if no Bluetooth
cation is being performed.
99
Device number:
This figure appears when the "Device Number" is activat-
ed in menu option "Display".
The figure can be set from 0 to 99.
See section "Display" under "Menu (Details)".
Lock:
This symbol means that the function of the keys and the
rotary knobs for controlling the WiCo are disabled.
The symbol no longer appears if the functions are enabled
once again by pressing the key button a second time.
Temperature Sensor:
This symbol appears when the external temperature sen-
sor is connected.
A
Operating Mode:
This symbol indicates the operating mode currently selected
(A, B, C, D).
USB:
This symbol means the WiCo is communicating or the
battery is charged via a USB cable. The symbol no longer
appears if no USB cable is being used for communicating
with the station.
Home:
This symbol means that the WiCo is connected to the
station and is communicating with the station via the
contacts.
The symbol no longer appears if the WiCo is removed
from the station.
® connection.
® :
station and the WiCo are com-
® .
® communi-
