- Check and make sure that the drain valve is closed
(rotate clockwise to the stop position, see Fig. 10).
Note: Please note information in section "Commission-
ing".
- Connect the power plug and turn on the device with
power switch (11).
- The low level icon (
WiCo. Meanwhile, the bottom LED segment of fluid
level indicator lights up in red color to indicate the low
fluid level.
- Open the filling opening lid (1) and remove the stopper
from the filling opening. Then, fill fluid to the bath.
Fig. 10
Note: Pay attention to the fluid level information.
Fluid level information on the WiCo display:
— Low level
— High level
Fluid level information on the fluid level indicator:
Red (High Level)
Red (Low Level)
Fig. 11
) appears on the display of the
Drain valve
Drain port
- To drain the fluid from the bath, connect a hose to the
drain port and turn the drain valve in counter clockwise
direction with a straight screwdriver.
Warning: Do not empty the bath while it is still cold,
there is a risk of freezing.
Fig. 12
