Mainboard Specification - AXIOMTEK SYM76996VGGA Manual

1.3 M
AINBOARD
Support Intel Ivy Bridge CPU
(Co-lay support Sandy Bridge CPU/Embedded CPU SKU)
CPU Intel® Core™ i7-2600 3.4GHz up to 95W
Intel® Core™ i5-2400 3.1GHz up to 95W
Intel® Core™ i3-2120 3.3HHz up to 65W
Chipset INTEL B75 chipset (Q77 by Option)
Intel® Integrated Graphic
Display Memory: Max. shared system memory up to 1759MB
Graphic
Resolution: VGA: Max. upto 2048 x 1536 at 75Hz
4x 240pin DDR3 SDRAM max up to 32GB
Each DIMM supports 512MB/ 1GB/2GB/4GB/8GB DDR3
Main Memory Dual Channel Mode DDR3 memory module
Supports DDR3 1066/1333, DDR3 1600 (Depending on CPU)
Registered DIMM and ECC DIMM is not supported
Chipset built-in Serial ATA controller
SATA Data transfer rates up to 3.0/6.0 Gb/s with RAID 0/1/5/10 support
SATA Version 2.0/3.0 specification compliant
1x INTEL 82574L for PCIe Gigabit LAN
LAN
1x INTEL 82579 PHY with Intel® AMT 7.0 support (by Q77 option)
Realtek ALC892
Sound Codec
5.1 channels audio out, High-Definition Audio support
LPC I/O ITE IT8728 (Support PECI 3.0)
PCI
Expansion PCIe x1
Slots PCIe x4
PCIe x16
SATA3 Connector
SATA2 Connector
System Fan Header
CPU Fan Header
Clear CMOS Header
USB 2.0 Connector
On Board
Front Panel Header
Connectors
Front Audio Connector
& Headers
Parallel Connector
Digital I/O Connector
Serial Connectors (RS-232)
Power Connector (24pin)
Power Connector (4pin)
TPM Header
PS/2 KB/MS
Back Panel
VGA
I/O
DVI-D
S
PECIFICATION
Specification
DVI-D: Max. upto 1920 x 1200 at 60Hz
x4
x1
x1
x1
x1
x5
x2
x1
x1
x3
x1
x1
x1
x1
x4
x1
x1
x1
x1
x1
x1
(Each connector supports x2 USB2.0 ports)
(4 input, 4 output)
(Max: 500mA output for each port)
(for PS/2 keyboard & mouse)
3
