SYM76996VGGA Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
Advertisement
Table of Contents
Related Manuals for AXIOMTEK SYM76996VGGA
Summary of Contents for AXIOMTEK SYM76996VGGA
- Page 1 SYM76996VGGA Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Introduction ........2 Before You Start ................2 Package Checklist ................2 Mainboard Specification..............3 Rear Panel Connectors ..............4 Motherboard Layout................. 5 Chapter 2: Hardware Installation ......6 Installing Central Processing Unit (CPU) ........6 FAN Headers .................. -
Page 3: Chapter 1: Introduction
User’s Manual CHAPTER 1: INTRODUCTION 1.1 B EFORE TART Thank you for choosing our product. Before you start installing the mainboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the system from power outlet before operation. -
Page 4: Mainboard Specification
1.3 M AINBOARD PECIFICATION Specification Support Intel Ivy Bridge CPU (Co-lay support Sandy Bridge CPU/Embedded CPU SKU) Intel® Core™ i7-2600 3.4GHz up to 95W Intel® Core™ i5-2400 3.1GHz up to 95W Intel® Core™ i3-2120 3.3HHz up to 65W Chipset INTEL B75 chipset (Q77 by Option) Intel®... -
Page 5: Rear Panel Connectors
User’s Manual Specification COM Port (Max : 500mA output for each port) USB2.0 Port RJ-45 (Gigabit LAN) Port Audio Jack Board Size 220 mm (W) x 305 mm (L) Operation 0°C ~ 60°C Temperature Storage -20°C ~ 80°C Temperature Relative 10% ~ 90% (non-condensing) Humidity Win7, WinXP... -
Page 6: Motherboard Layout
1.5 M OTHERBOARD AYOUT Note: ■ represents the 1 pin. -
Page 7: Chapter 2: Hardware Installation
User’s Manual CHAPTER 2: HARDWARE INSTALLATION 2.1 I (CPU) NSTALLING ENTRAL ROCESSING Notice: Remove Pin Cap before installation, and make good preservation for future use. When the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged. - Page 8 Step 3: Hold processor with your thumb and index fingers, oriented as shown. Align the notches with the socket. Lower the processor straight down without tilting or sliding the processor in the socket. Step 4: Close the load plate. Pressing down on the load plate, close and engage the socket lever.
-
Page 9: Fan Headers
User’s Manual 2.2 FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. -
Page 10: Installing System Memory
2.3 I NSTALLING YSTEM EMORY A. Memory Modules Step1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. - Page 11 User’s Manual Step2: Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated. Note: If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again. B.
-
Page 12: Power Supply
OWER UPPLY ATXPWR1: ATX Power Source Connector (24-pin) This connector allows user to connect 24-pin power connector. Assignment Assignment +3.3V +3.3V +3.3V -12V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage +5V +12V +12V +3.3V Ground JATXPWR2: ATX Power Source Connector (4-pin) This connector provides +12V to system power circuit. -
Page 13: Onboard Slot/Connector/Header/Jumper
User’s Manual NBOARD ONNECTOR EADER UMPER PEX16_1: PCI-Express x16 Slot PCI-Express 3.0 compliant. Maximum theoretical realized bandwidth of 16GB/s simultaneously per direction, for an aggregate of 32GB/s totally. PCI-Express Gen3 is supported by Core i7-3xxx / i5-3xxx CPUs. PEX1_1: PCI-Express x1 Slot PCI-Express 2.0 compliant. - Page 14 PCI1 ~ PCI4: Peripheral Component Interconnect Slots This motherboard is equipped with 4 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits. JPANEL1: Front Panel Header This 10-pin header includes Power-on, Reset, HDD LED, and Power LED connection.
- Page 15 User’s Manual JCMOS1: Clear CMOS Header Placing the jumper on pin2-3 allows user to restore the BIOS safe setting and the CMOS data. Please carefully follow the procedures to avoid damaging the mainboard. Pin 1-2 Close: (Default) Normal Operation. Pin 2-3 Close: Clear CMOS data.
- Page 16 SATA2/3/4/5: Serial ATA2 Connectors The connectors connect to Serial ATA 3.0Gb/s hard disk drive and optical disc drive. Assignment F_USB1/2/3: USB 2.0 Connectors The mainboard provides 3 front USB pin connector, allowing up to 6 additional USB 2.0 ports up to maximum throughput of 480 Mbps. Connect the USB cable into the pin header for using high-speed USB interface peripherals.
- Page 17 User’s Manual Serial Port Connectors: The motherboard has 6 Serial Port Connectors for connecting RS-232 Port. JCOM1/2: Serial Port Connectors Assignment Carrier detect (DCD) Received data (RXD) Transmitted data (TXD) Data terminal ready (DTR) Signal ground (GND) Data set ready (DSR) Request to send (RTS) Clear to send (CTS) Ring / 5V / 12V...
- Page 18 JSEL1/JSEL2: RS-232/422/485 Switch Headers for JCOM1 The headers determine that JCOM1 belongs to RS-232 (Default), 422, or 485. JSEL1 RS-232 RS-422 RS-485 9-11 9-11 8-10 10-12 10-12 JSEL2 RS-232 RS-422 RS-485...
- Page 19 User’s Manual JCOM3/4/5/6: Serial Port Connectors Pin Assignment Pin Assignment -PDCD PSIN PSOUT data -PDTR -PDSR -PRTS -PCTS Ring/5V/12V JP3/4/5/6: Voltage Switch jumpers for JCOM3/4/5/6 ports The headers are for controlling the Pin9 of JCOM3/4/5/6 ports to switch Ring/5V/12V. Pin 1-2 Close: Pin9=5V Pin 3-4 Close: Pin9=Ring...
- Page 20 F_AUDIO1: Front Panel Audio Header This is an interface for the front panel audio cable that allows convenient connection and control of audio devices. This header allows only HD audio front panel connector; AC’97 connector is not acceptable.. Pin Assignment Pin Assignment Mic Left in Ground...
- Page 21 User’s Manual JDIO1: Digital I/O Connector This connector offers 4-pair of digital I/O functions and address is set in BIOS. The default address is: DI01 -> A22H BIT5-> GPIO35 DI02 -> A22H BIT4> GPIO34 DI03 -> A20H BIT4-> GPIO14 DI04 -> A24H BIT0-> GPIO50 DO01 ->...
- Page 22 TPM1: Trusted Platform Module Header This header allows you to store cryptographic keys that protect information Assignment Assignment CLK_PCI_TPM Ground LFRAME# PL_RST2# VCC5 FWH3 FWH2 VCC3_3 FWH1 FWH0 Ground SMBCLK SMBDATA AUX33 SERIRQ Ground CLK_RUN# SUS_STAT# LDRQJ1 *How to Setup Jumpers The illustration shows how to set up jumpers.
