www.adeept.com
2.2. Servo debugging.
1.
Fix four M2.5x10+6 Copper Standoffs on Raspberry Pi.
insert the Adeept Motor HAT into Raspberry Pi.
and
Assemble the following components
M2.5x10+6 Copper
Raspberry Pi x1
Standoff x4
M2.5x48
Screw x4
Adeept Motor
HAT x1
Effect diagram after assembling
9
