- Page 1 True 4K HDMI HDBaseT-Lite Extender VE1830 User Manual www.aten.com...
-
Page 2: Emc Information
VE1830 User Manual EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: User Information
Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 1-949-428-1111 User Notice All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. The manufacturer makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties as to merchantability or fitness for any particular purpose. -
Page 4: Package Contents
VE1830 User Manual Package Contents 1 VE1830T True 4K HDMI HDBaseT-Lite Extender Transmitter 1 VE1830R True 4K HDMI HDBaseT-Lite Extender Receiver 2 RS-232 Terminal Blocks 1 Power Adapters 1 User Instructions Note: 1. Make sure that all of the items are present and in good order. If anything is missing or was damaged in shipping, please contact your dealer for further assistance. -
Page 5: Table Of Contents
VE1830T ........ -
Page 6: About This Manual
Read this manual thoroughly and follow the installation and operation procedures carefully to prevent any damage to the unit or any connected devices. ATEN regularly updates its product documentation for new features and fixes. For an up-to-date VE1830 documentation, visit http://www.aten.com/global/en/... -
Page 7: Conventions
Indicates critical information. Product Information For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com... - Page 8 VE1830 User Manual This Page Intentionally Left Blank viii...
-
Page 9: Introduction
Overview The VE1830 True 4K HDMI HDBaseT-Lite Extender provides great flexibility in professional A/V installation with its high-quality transmitter VE1830T and receiver VE1830R. Powered by HDBaseT™ technology, the VE1830 transmits True 4K HDMI signals up to 35m using a single Cat 5e/6 cable. ThisHDBaseT- Lite Extender supports HDCP 2.2 and meets the HDMI 2.0a specifications (3D,... -
Page 10: Features
Extends full HD 1080p signals up to 70 m Supports HDR10+* features PoC (Power over Cable) - supplies power from the VE1830T unit to the VE1830R unit Features RS-232 serial port for connecting peripherals such as touch screens, and barcode scanners ... -
Page 11: Requirements
To connect the VE1830 transmitter and receiver units, we recommend using cables of Cat 5e/6/6a to ensure video quality. For better video quality, we strongly suggest using ATEN 2L-2910 Cat 6 cable. Maximum cable distances are as follow:... -
Page 12: Considerations
Chapter 1. Introduction This Page Intentionally Left Blank... -
Page 13: Hardware Setup
1. Please review the safety information regarding the placement of this device in Safety Instructions, page 11. 2. Do not power on the VE1830 until all the necessary hardware is connected. Hardware Overview VE1830T Component Description Power LED Lights blue: The unit is receiving power. - Page 14 Firmware Upgrade Switch The Firmware Upgrade port is reserved for technical support. If you would like to do a firmware upgrade yourself, please contact your dealer. HDMI In Connects the HDMI In port on the VE1830T to the HDMI output port on the video source device using an HDMI cable.
-
Page 15: Ve1830R
VE1830 User Manual VE1830R Component Description Power LED Lights blue: The unit is receiving power. Link LED Lights blue: The connection to the Transmitter and Receiver units are stable. Flashes blue: The connection to the Transmitter and Receiver units are unstable. Off: When there is no connection to the Transmitter and Receiver units. -
Page 16: Hardware Installation
Chapter 2. Hardware Setup Hardware Installation Follow the steps below to safely install the VE1830 to a source, a display device, and other devices as required. VE1830T Serial Device HDMI Source VE1830R Serial Device Monitor... - Page 17 Extends 4K/2K, 60Hz HDMI signals (4:4:4) up to 35 m 2. To extend an HDMI source, do the following: a) Connect the HDMI In port on the VE1830T to the HDMI Out port of your video source using an HDMI cable.
-
Page 18: Rs-232 Channel Transmission
Chapter 2. Hardware Setup RS-232 Channel Transmission You can utilize the VE1830 to extend RS-232 serial control signals between two serial devices, for example, such as a computer and a bar code scanner. The flow of the RS-232 signal transmission can be illustrated as follows: Fiber Serial Device... -
Page 19: Appendix
Appendix Safety Instructions General This product is for indoor use only. Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 20 Appendix If an extension cord is used with this device make sure that the total of the ampere ratings of all products used on this cord does not exceed the extension cord ampere rating. Make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes.
-
Page 21: Technical Support
Support Documentation Software Updates Telephone Support 1-888-999-ATEN ext 4988 When you contact us, please have the following information ready beforehand: Product model number, serial number, and date of purchase Your computer configuration, including operating system, revision level, expansion cards, and software ... -
Page 22: Specifications
Max. Resolutions / Up to True 4K: 3840 x 2160 @ 60Hz (4:4:4) @35m (Cat 5e/6); Distances Up to 1080p @70m (Cat 6a/ATEN 2L-2910 Cat 6) Supported 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0) @35m (Cat 5e/6);... - Page 23 VE1830 User Manual Function VE1830R VE1830T Switches Firmware Upgrade 1 x Slide Switch - ON/OFF Environmental Operating 0 - 40°C Temperature Storage Temperature -20 - 60°C Humidity 0 x 80% RH, Non-Condensing Physical Properties Housing Metal Weight 0.12 kg (0.28 lb) 0.15 kg (0.35 lb)
-
Page 24: Limited Warranty
ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or repaired components, or (2) replace the entire product with an identical product or with a similar product which fulfills the same function as the defective product.
