ATEN VE150A Specification

VE150A
Video Extender
VE150A video extender comprises a local transmitting unit and
a remote receiving unit which are connected by standard Cat 5e
cables. The distance of both units can be extended up to 150m.
It is ideal for factories and construction sites, or any location
where the display may need to expose in a risky setting, but you
want the system to be kept in a safe location.
Video Out
Video In
Features
• Uses Cat 5e cables to connect the local and remote units
• Supports one local and one remote display
• Long distance transmission – up to 150 m
• Adjustable gain control - manually adjust signal strength to
compensate for distance
• Superior video quality – up to 1920x1200 (30 m);
1600x1200 (100 m); 1280x1024 (150 m)
• Supports VGA, XGA, SVGA, UXGA, WUXGA, and multisync
monitors
• Supports wide screen formats
• Supports hot-plugging
• Built-in 8KV/15KV ESD protection
• Supports DDC for the local monitor
• Easy installation
• Rack Mountable
• Plug-and-play – no software installation required
ATEN International Co., Ltd.
3F., No.125, Sec. 2, Datong Rd., Sijhih District., New Taipei City 221, Taiwan
Phone: 886-2-8692-6789 Fax: 886-2-8692-6767
www.aten.com E-mail: marketing@aten.com
Professional A/V Solutions
Local
VE150AT (Front)
VE150AT (Rear)
Specification
Function
Display Connections
Input Video
1 x HDB-15 Female
Output Video
Connectors
Unit to Unit
Power
Manual Gain
Switches
Control
LEDs Power
1920x1200 @ 60Hz (30 m); 1600x1200
Video
Power Consumption
Operating
Temp.
Environment
Storage Temp
Humidity
Housing
Physical Weight
Properties
Dimensions
(L x W x H)
© Copyright 2012 ATEN® International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd.
All rights reserved. All other trademarks are the property of their
respective owners.
Remote
VE150AR (Front)
VE150AR (Rear)
VE150AT VE150AR
1 1
1 x HDB-15 Male
N/A
(Blue)
1 x HDB-15 Female
(Blue) (Blue)
1 x RJ-45 Female 1 x RJ-45 Female
(Black) (Black)
1 x DC Jack 1 x DC Jack
N/A 1 x Knob
1 (Green) 1 (Green)
@ 60Hz (100 m); 1280x1024 @ 60Hz
(150 m)
DC5.3V, 1.0W DC5.3V, 1.2W
0–50ºC
-20–60ºC
0–80% RH, Non-condensing
Metal
0.24kg
12.77 x 9.04 x 2.26 cm
Printed 09/2012 V1.0
