DITEC CROSS3E-73R Quick Reference page 4

4. 73R STANDARD SETTING
5. RADIO ENABLING
SIG
PRG
NIO
JR3
6. AUTOMATIC CLOSING SETTING
120 s
MIN=0 s MAX
i
For different setting and further information consult the CROSS3E, CROSS5EH, CROSS7EH automation instruction
manual, the 73R control panel instruction manual and BIXLR22 radio instruction manual.
DITEC S.p.A.
Via Mons. Banfi, 3 - 21042 Caronno Pertusella (VA) - ITALY
Tel. +39 02 963911 - Fax +39 02 9650314
www.ditec.it - ditec@ditecva.com
CROSS3E/5EH/7EH-73R QUICK REFERENCE - IP2006
DIP2 = ON
LEFT OPENING
DIP1 = ON
OPENING RADIO MODE
DIP1 = OFF
STEP BY STEP RADIO MODE
DIP2 = OFF
RIGHT OPENING
C NO
1°
Push PRG
Led SIG comes on
SIG
-
+
MAX
1°
TC time setting
DISABLED!
SO JR4
ON
1 2 3 4 5
OFF
JR3
VA VC TC R1
14 13 12 11 0 1 1 5 6 8 9 20 41
2°
Push CH
GOL4-GOL4C
120 s
MIN=0 s MAX
2°
4
NIO
Led SIG flashes 3 times
SIG
-
+
TC time setting
ENABLED!
Wait for 10 s
