2. General Information and Ratings

2.1. Drive model numbers
2.1.1. IP20 Enclosed Units
200-240V ±10% - 1 Phase Input
kW Model
ODV-2-22075-1KF12-SN
ODV-2-22150-1KF12-SN
ODV-2-22220-1KF12-SN
200-240V ±10% - 3 Phase Input
kW Model
ODV-2-22075-3KF12-SN
ODV-2-22150-3KF12-SN
ODV-2-22220-3KF12-SN
ODV-2-32040-3KF12-SN*
ODV-2-32055-3KF12-SN
380-480V ±10% - 3 Phase Input
kW Model Number
ODV-2-24075-3KF12-SN
ODV-2-24150-3KF12-SN
ODV-2-24220-3KF12-SN
ODV-2-24400-3KF12-SN
ODV-2-34055-3KF12-SN
ODV-2-34075-3KF12-SN
ODV-2-34110-3KF12-SN
500 – 600V ±10% - 3 Phase Input
kW Model Number
ODV-2-26075-3K012-SN
ODV-2-26150-3K012-SN
ODV-2-26220-3K012-SN
ODV-2-26400-3K012-SN
ODV-2-26055-3K012-SN
ODV-2-36075-3K012-SN
ODV-2-36110-3K012-SN
ODV-2-36150-3K012-SN
* Note : The final two characters of the model number relate to available factory build options as follows
-SN Standard Seven Segment LED Display, standard PCB coating
-SC Standard Seven Segment LED Display, additional PCB conformal coating
2.1.2. IP66 Enclosed Units
200-240V ±10% - 1 Phase Input
kW Model
Non Switched
*
ODV-2-22075-1KF1X-TN ODV-2-22075-1KF1D-TN
*
ODV-2-22150-1KF1X-TN ODV-2-22150-1KF1D-TN
*
ODV-2-22220-1KF1X-TN ODV-2-22220-1KF1D-TN
200-240V ±10% - 3 Phase Input
kW Model Number
Non Switched
*
ODV-2-22075-3KF1X-TN ODV-2-22075-3KF1D-TN
*
ODV-2-22150-3KF1X-TN ODV-2-22150-3KF1D-TN
*
ODV-2-22220-3KF1X-TN ODV-2-22220-3KF1D-TN
*
ODV-2-32040-3KF1X-TN ODV-2-32040-3KF1D-TN
380-480V ±10% - 3 Phase Input
kW Model Number
Non Switched
*
ODV-2-24075-3KF1X-TN ODV-2-24075-3KF1D-TN
*
ODV-2-24150-3KF1X-TN ODV-2-24150-3KF1D-TN
*
ODV-2-24220-3KF1X-TN ODV-2-24220-3KF1D-TN
*
ODV-2-24400-3KF1X-TN ODV-2-24400-3KF1D-TN
*
ODV-2-34055-3KF1X-TN ODV-2-34055-3KF1D-TN
*
ODV-2-34075-3KF1X-TN ODV-2-34075-3KF1D-TN
500-600V ±10% - 3 Phase Input
kW Model Number
Non Switched
*
ODV-2-26075-3K01X-TN ODV-2-26075-3K01D-TN
*
ODV-2-26150-3K01X-TN ODV-2-26150-3K01D-TN
*
ODV-2-26220-3K01X-TN ODV-2-26220-3K01D-TN
*
ODV-2-26400-3K01X-TN ODV-2-26400-3K01D-TN
*
ODV-2-26550-3K01X-TN ODV-2-36550-3K01D-TN
*
ODV-2-36075-3K01X-TN ODV-2-36075-3K01D-TN
Optidrive HVAC User Guide V2.00
kW HP Model
*
0.75 ODV-2-22010-1HF12-SN
*
1.5 ODV-2-22020-1HF12-SN
*
2.2 ODV-2-22030-1HF12-SN
kW HP Model
*
0.75 ODV-2-22010-3HF12-SN
*
1.5 ODV-2-22020-3HF12-SN
*
2.2 ODV-2-22030-3HF12-SN
4 ODV-2-32050-3HF12-SN
*
5.5 ODV-2-32075-3HF12-SN
kW HP Model Number
*
0.75 ODV-2-24010-3HF12-SN
*
1.5 ODV-2-24020-3HF12-SN
*
2.2 ODV-2-24030-3HF12-SN
*
4 ODV-2-24050-3HF12-SN
*
5.5 ODV-2-34075-3HF12-SN
*
7.5 ODV-2-34100-3HF12-SN
*
11 ODV-2-34150-3HF12-SN
kW HP Model Number
*
0.75 ODV-2-26010-3H012-SN
*
1.5 ODV-2-26020-3H012-SN
*
2.2 ODV-2-26030-3H012-SN
*
4 ODV-2-26050-3H012-SN
*
5.5 ODV-2-26075-3H012-SN
*
7.5 ODV-2-36100-3H012-SN
*
11 ODV-2-36150-3H012-SN
*
15 ODV-2-36200-3H012-SN
kW
Switched Non Switched
*
0.75 ODV-2-22010-1HF1X-TN
*
1.5 ODV-2-22020-1HF1X-TN
*
2.2 ODV-2-22030-1HF1X-TN
kW
Switched Non Switched
*
0.75 ODV-2-22010-3HF1X-TN
*
1.5 ODV-2-22020-3HF1X-TN
*
2.2 ODV-2-22030-3HF1X-TN
*
4 ODV-2-32050-3HF1X-TN
kW
Switched Non Switched
*
0.75 ODV-2-24010-3HF1X-TN
*
1.5 ODV-2-24020-3HF1X-TN
*
2.2 ODV-2-24030-3HF1X-TN
*
4 ODV-2-24050-3HF1X-TN
*
5.5 ODV-2-34075-3HF1X-TN
*
7.5 ODV-2-34100-3HF1X-TN
kW HP Model Number
Switched Non Switched
*
0.75 ODV-2-26010-3H01X-TN
*
1.5 ODV-2-26020-3H01X-TN
*
2.2 ODV-2-26030-3H01X-TN
*
4 ODV-2-26050-3H01X-TN
*
5.5 ODV-2-26075-3H01X-TN
*
7.5 ODV-2-36100-3H01X-TN
www.invertekdrives.com
HP Output Current (A)
*
1 4.3
*
2 7
*
3 10.5
HP Output Current (A)
*
1 4.3
*
2 7
*
3 10.5
*
5 18
*
7.5 24
HP Output Current (A)
*
1 2.2
*
2 4.1
*
3 5.8
*
5 9.5
*
7.5 14
*
10 18
*
15 24
HP Output Current (A)
*
1 2.1
*
2 3.1
*
3 4.1
*
5 6.5
*
7.5 9
*
10 12
*
15 17
*
20 22
HP Model
Switched
*
ODV-2-22010-1HF1D-TN
*
ODV-2-22020-1HF1D-TN
*
ODV-2-22030-1HF1D-TN
HP Model Number
Switched
*
ODV-2-22010-3HF1D-TN
*
ODV-2-22020-3HF1D-TN
*
ODV-2-22030-3HF1D-TN
*
ODV-2-32050-3HF1D-TN
HP Model Number
Switched
*
ODV-2-24010-3HF1D-TN
*
ODV-2-24020-3HF1D-TN
*
ODV-2-24030-3HF1D-TN
*
ODV-2-24050-3HF1D-TN
*
ODV-2-34075-3HF1D-TN
*
ODV-2-34100-3HF1D-TN
Switched
*
ODV-2-26010-3H01D-TN
*
ODV-2-26020-3H01D-TN
*
ODV-2-26030-3H01D-TN
*
ODV-2-26050-3H01D-TN
*
ODV-2-26075-3H01D-TN
*
ODV-2-36100-3H01D-TN
Frame Size
2
2
2
Frame Size
2
2
2
3
3
Frame Size
2
2
2
2
3
3
3
Frame Size
2
2
2
2
2
3
3
3
HP Output Frame
Current (A) Size
*
1 4.3 2
*
2 7 2
*
3 10.5 2
HP Output Frame
Current (A) Size
*
1 4.3 2
*
2 7 2
*
3 10.5 2
*
5 18 3
HP Output Frame
Current (A) Size
*
1 2.2 2
*
2 4.1 2
*
3 5.8 2
*
5 9.5 2
*
7.5 14 3
*
10 18 3
HP Output Frame
Current (A) Size
*
1 2.1 2
*
2 3.1 2
*
3 4.1 2
*
5 6.5 2
*
7.5 9 2
*
10 12 3
