* Note : The final two characters of the model number relate to available factory build options as follows
-TN OLED Text Display, standard PCB coating
-TC OLED Text Display, additional PCB conformal coating
2.1.3. IP55 Enclosed Units
200-240V ±10% - 3 Phase Input
kW Model Number
ODV-2-42055-3KF1N-TN
ODV-2-42075-3KF1N-TN
ODV-2-42110-3KF1N-TN
ODV-2-52150-3KF1N-TN
ODV-2-52185-3KF1N-TN
ODV-2-62022-3KF1N-TN
ODV-2-62030-3KF1N-TN
ODV-2-62037-3KF1N-TN
ODV-2-62045-3KF1N-TN
ODV-2-72055-3KF1N-TN
ODV-2-72075-3KF1N-TN
380-480V ±10% - 3 Phase Input
kW Model Number
ODV-2-44110-3KF1N-TN
ODV-2-44150-3KF1N-TN
ODV-2-44185-3KF1N-TN
ODV-2-44220-3KF1N-TN
ODV-2-54300-3KF1N-TN
ODV-2-54370-3KF1N-TN
ODV-2-64045-3KF1N-TN
ODV-2-64055-3KF1N-TN
ODV-2-64075-3KF1N-TN
ODV-2-64090-3KF1N-TN
ODV-2-74110-3KF1N-TN
ODV-2-74132-3KF1N-TN
ODV-2-74160-3KF1N-TN
480-525V ±10% - 3 Phase Input
kW Model Number
ODV-2-75132-3K01N-TN
ODV-2-75150-3K01N-TN
ODV-2-75185-3K01N-TN
ODV-2-75200-3K01N-TN
500-600V ±10% - 3 Phase Input
kW Model Number
ODV-2-46185-3K01N-TN
ODV-2-46220-3K01N-TN
ODV-2-56300-3K01N-TN
ODV-2-56370-3K01N-TN
ODV-2-56450-3K01N-TN
ODV-2-66055-3K01N-TN
ODV-2-66075-3K01N-TN
ODV-2-66090-3K01N-TN
ODV-2-66110-3K01N-TN
* Note : The final two characters of the model number relate to available factory build options as follows
-TN OLED Text Display, standard PCB coating
-TC OLED Text Display, additional PCB conformal coating
10
Optidrive HVAC User Guide V2.00
kW HP Model Number
*
5.5 ODV-2-42075-3HF1N-TN
*
7.5 ODV-2-42100-3HF1N-TN
*
11 ODV-2-42150-3HF1N-TN
*
15 ODV-2-52020-3HF1N-TN
*
18.5 ODV-2-52025-3HF1N-TN
*
22 ODV-2-62030-3HF1N-TN
*
30 ODV-2-62040-3HF1N-TN
*
37 ODV-2-62050-3HF1N-TN
*
45 ODV-2-62060-3HF1N-TN
*
55 ODV-2-72075-3HF1N-TN
*
75 ODV-2-72100-3HF1N-TN
kW HP Model Number
*
11 ODV-2-44150-3HF1N-TN
*
15 ODV-2-44200-3HF1N-TN
*
18.5 ODV-2-44250-3HF1N-TN
*
22 ODV-2-44300-3HF1N-TN
*
30 ODV-2-54040-3HF1N-TN
*
37 ODV-2-54050-3HF1N-TN
*
45 ODV-2-64060-3HF1N-TN
*
55 ODV-2-64075-3HF1N-TN
*
75 ODV-2-64120-3HF1N-TN
*
90 ODV-2-64150-3HF1N-TN
*
110 ODV-2-74175-3HF1N-TN
*
132 ODV-2-74200-3HF1N-TN
*
160 ODV-2-74250-3HF1N-TN
kW HP Model Number
*
132
*
150
*
185
*
200
kW HP Model Number
*
18.5 ODV-2-46250-3H01N-TN
*
22 ODV-2-46300-3H01N-TN
*
30 ODV-2-56400-3H01N-TN
*
37 ODV-2-56050-3H01N-TN
*
45 ODV-2-56060-3H01N-TN
*
55 ODV-2-66075-3H01N-TN
*
75 ODV-2-66100-3H01N-TN
*
90 ODV-2-66125-3H01N-TN
*
110 ODV-2-66150-3H01N-TN
www.invertekdrives.com
HP Output Current (A)
*
7.5 24
*
10 30
*
15 46
*
20 61
*
25 72
*
30 90
*
40 110
*
50 150
*
60 180
*
75 202
*
100 248
HP Output Current (A)
*
15 24
*
20 30
*
25 39
*
30 46
*
40 61
*
50 72
*
60 90
*
75 110
*
120 150
*
150 180
*
175 202
*
200 240
*
250 302
HP Output Current (A)
185
205
255
275
HP Output Current (A)
*
25 28
*
30 34
*
40 43
*
50 54
*
60 65
*
75 78
*
100 105
*
125 130
*
150 150
Frame Size
4
4
4
5
5
6
6
6
6
7
7
Frame Size
4
4
4
4
5
5
6
6
6
6
7
7
7
Frame Size
7
7
7
7
Frame Size
4
4
5
5
5
6
6
6
6
