Manual
ISOMETER® isoPV
coupling device AGH-PV
Insulation monitoring device for unearthed
IT AC, AC/DC and DC systems
for photovoltaic systems up to AC 793 V / DC 1100 V
Software version: D351 V2.0
isoPV_D00024_00_M_XXDE/06.2015
