An Accelerator card has two LEDs:
■ LED 1 glows or flashes green or yellow.
■ LED 2 glows or flashes green or red.
Table 10: Accelerator card LED states
Server state LED 1
Power up
POST
State save
State restore
Upgrade
Chapter 4: Server troubleshooting
Off
Off
Off
Off
Off
Flashing yellow
Steady yellow
Steady green
Steady yellow
Flashing yellow
Flashing green
LED 2
Off
Steady red
Flashing red (1 on, 1
off)
Steady green
Flashing red (2 on, 2
off)
Steady green
Steady red
Steady green
Flashing green
Flashing green
Flashing green
Description
PCIe 12V power is not
present.
Configuration
Programmable Logic
Device (CPLD) detected
power failure or CPLD is
not configured.
Field Programmable
Gate Array (FPGA)
configuration error or
configuration failed.
FPGA configuration is
complete.
Firmware is not
responding to health
check.
Power-on self test
(POST) is executing.
POST failure.
Normal operation
(passed POST).
NVRAM state save in
progress.
NVRAM state restore in
progress.
Firmware upgrade in
progress.
