Callout Component
3 Storage
4 Control panel
5 Diagnostic indicators
6 Server identification button/LED
Chapter 1: Hardware overview
Description
24 drives, size 2.5", with activity (right)
and fault (left) LED indicators.
An embossed number on the enclosure
shows the drive numbering from 1 to
24, left to right.
■ The Remote Site model contain
6 disks: Disks 1 and 2 are SSDs.
Disks 3 to 6 are HDDs.
■ The Small model contains 10 disks:
Disks 1 and 2 are SSDs. Disks 3 to
10 are HDDs.
■ The Medium and Large models
contain 24 disks (shown above):
Disks 1 to 4 are SSDs. Disks 5 to 24
are HDDs.
■ The Small, All Flash model contains
5 SSD disks numbered 1 through 5.
■ The Medium, All Flash model
contains 10 SSD disks numbered 1
through 10.
■ The Large, All Flash model contains
14 SSD disks numbered 1 through
14.
Provides server status and control
features.
Shows any detected hardware error
conditions, or indicates normal healthy
function.
Server identification button.
The server identification button helps
locate an enclosure within a rack.
If you push the server identification
button on the back panel (or the front
panel), the server identification buttons
on the front panel and the back panel
flash blue. You can push a server
identification button a second time to
stop it from flashing.
