Table Of Contents - ASL INTERCOM MPS Series Installation Manual

This equipment is designed and manufactured to conform to the following EC standards:
EMC:
Safety:
A "Declaration of Conformity" statement to the above standards is available on request.
Voice Alarm: When installed in a Voice Alarm system designed and configured in accordance with the
CPR:
A 'Declaration of Performance According to the Construction Products Regulation (EU)
No. 305/2011' for ASL's Voice Alarm Control and Indicating Equipment (VACIE) is available on request.
Failure to use the equipment in the manner described in the product literature will invalidate the warranty.
This product must be disposed of in accordance with the WEEE directive.
Contents
1 Technical Specification ............................................................................................................................................... 3
2 Controls and Indicators ............................................................................................................................................... 5
3 Installation................................................................................................................................................................... 7
4 Connections.............................................................................................................................................................. 18
5 Mechanical Dimensions ............................................................................................................................................ 22
6 Safety and Precautions............................................................................................................................................. 23
Additional User Documentation:
Additional reference information is available from the ASL's website at www.asl-control.co.uk
Copyright © 2014 Application Solutions (Safety and Security) Limited
Application Solutions (Safety and Security) Limited
Unit 17 Cliffe Industrial Estate
Lewes - East Sussex
BN8 6JL - UK
Tel: +44(0)1273 405411
www.asl-control.co.uk
All rights reserved.
Information contained in this document is believed to be accurate. However, no representation or warranty is given and Application
Solutions (Safety and Security) Limited assumes no liability with respect to the accuracy of such information.
MPS-Series - Installation Guide
EN 55103-1/E1-E5, EN 55103-2/E5, EN 50121-4, EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4 and EN 55022/B
EN 60065 (pollution degree 2)
ASL's EN 54-16 & ISO 7240-16 System Design Guide (T-0667-0016), this product meets the
requirement of harmonised standards (as applicable):
EN 54-16 and EN 54-4
Fax: +44(0)1273 405415
U-0664-0174.doc - Issue: 07 complete, approved
Page 2 of 24
