FrameSaver SLV 9126/9128
1-Slot Unit
Installation Instructions
Document Number 9128-A2-GN12-00
December 1999
Product Documentation on the World Wide Web
We provide complete product documentation online. This lets you search the
documentation for specific topics and print only what you need, reducing the waste of
surplus printing. It also helps us maintain competitive prices for our products.
Complete documentation for this product is available at www.paradyne.com.
Select Library
Select the following document:
9128-A2-GB20
FrameSaver SLV 9126/9128 User's Guide
To request a paper copy of a Paradyne document:
Within the U.S.A., call 1-800-PARADYNE (1-800-727-2396)
Outside the U.S.A., call 1-727-530-8623
Package Checklist
Verify that your package contains the following:
FrameSaver SLV unit
Power cord with desktop power transformer.
— 120 Vac power transformer for a FrameSaver 9128.
— 100 – 240 Vac power transformer for a FrameSaver 9126.
T1 network cable
DSX adapter if a FrameSaver 9126 (1 foot – 0.3048 meters)
ISDN PRI or BRI cable, if applicable
FrameSaver SLV 9126/9128 Quick Reference (Document No. 9128-A2-GL10)
Be sure to register your warranty at www.paradyne.com/warranty.
Technical Manuals
FrameSaver Frame Relay Devices.
1

Advertisement

Table of Contents
loading

Related Manuals for Paradyne FrameSaver SLV 9126

Summary of Contents for Paradyne FrameSaver SLV 9126

  • Page 1 We provide complete product documentation online. This lets you search the documentation for specific topics and print only what you need, reducing the waste of surplus printing. It also helps us maintain competitive prices for our products. Complete documentation for this product is available at www.paradyne.com. Select Library Technical Manuals FrameSaver Frame Relay Devices.

  • Page 2: Before You Begin

    Before You Begin Make sure you have: A dedicated, grounded power outlet that is protected by a circuit breaker within 6 feet of the FrameSaver SLV (service level verifier) unit. A clean, well-lit, and ventilated site that is free from environmental extremes. One-to-two feet of clearance for cable connections.

  • Page 3: Safety Instructions

    Safety Instructions Read the Important Safety Instructions and EMI Warnings beginning on page 19. Installing the Power Supply and Cord 1. Insert the 4-prong plug into the POWER jack. When inserting the plug at the rear of the FrameSaver unit, align the plug with the notch above the POWER jack.

  • Page 4: Connecting The Com Port To An Asynchronous Terminal

    Connecting the COM Port to an Asynchronous Terminal The FrameSaver unit must first be directly connected to a VT100-compatible asynchronous terminal or a PC providing VT100 terminal emulation to set up access and management of the unit. 1. Configure the terminal or PC to be compatible with the FrameSaver unit: –...

  • Page 5: A Quick Guide To Configuration

    A Quick Guide to Configuration The FrameSaver unit should operate using the default (factory-set) configuration options, except for the changes specified in these installation instructions. Refer to the following table for help navigating the menus. Press the . . . To .

  • Page 6: Verifying That Self-Test Passed

    The FrameSaver unit is set to automatically configure the following: Time Slot Assignment Auto-Configuration It is assumed that the unit is configured for factory default settings at the start of the installation, and that the automatic configuration features will be used. See Time Slot Assignment on page 7 and Automatic Configuration on page 9 for information about these features.

  • Page 7: Time Slot Assignment

    Setting Up Physical Interfaces 1. Select each interface’s physical configuration options. Configuration Network Physical Configuration Data Ports Physical Configuration DSX-1 (if the DSX-1 interface will be used) If installing a FrameSaver SLV NAM with an ISDN DBM, postpone configuring the DBM interface until later.

  • Page 8: Setting Up The Modem

    Setting Up the Modem The unit has an integral modem for remote management. It is already set up for dial-in access to the unit, with Port Use set to Terminal. If using the modem for dialed IP network connectivity (SNMP, Telnet, FTP, or trap dial-out): 1.

  • Page 9: Setting Up Management

    Setting Up Management 1. Select General SNMP Management. Configuration Management and Communication General SNMP Management 2. Minimally, set Name 1 Access to Read/Write. 3. Save the configuration. Setting Up Local Management at the Central Site 1. Create a DLCI for the data port. Configuration Data Ports DLCI Records...

  • Page 10: Connecting To The Network

    Connecting to the Network 1. Insert the 8-pin connector of the RJ48C network cable into the network interface. 2. Insert the other end of the cable into the RJ48C modular jack. RJ48C or RJ48S Jack MODEM NET POWER (FrameSaver 9128 Shown) 99-16630 NOTE:...

  • Page 11: Setting Up The Isdn Dbm

    Setting Up the ISDN DBM FrameSaver 9128 units may be equipped with an ISDN PRI or BRI DBM. These instructions are for units with ISDN backup capability. The following guidelines apply: Central site configuration guidelines: – Set up the ISDN DBM physical interface. –...
  • Page 12 Setting Up Automatic Backup Configuration The Automatic Backup Configuration feature is used to automatically create alternate DLCI records and PVC connections on the ISDN DBM (backup) interface. This feature is already set up in FrameSaver units with a DBM. Single_Site_Backup is the default for a BRI DBM. Multi_Site_Backup is the default for a PRI DBM.

  • Page 13: Setting Up Service Provider Connectivity At The Central Site

    Setting Up Service Provider Connectivity at the Central Site When management needs to be set up between a service provider’s customer and its network operations center (NOC), a non-multiplexed DLCI must be configured to carry management data between the customer’s central site and the NOC console. This requires that a frame relay discovered DLCI needs to be modified.

  • Page 14: Verifying The End-To-End Path

    Verifying the End-to-End Path After installation of a remote site unit, run an IP Ping test to Ping the NMS at the central site and verify that the entire path from the remote unit to the NMS is functioning. To run the IP Ping test, NMS trap managers must have been configured for the remote unit.

  • Page 15: Connecting To The Dte

    Verification Check: Check the DSX LEDs. Is the Sig (DSX-1 signal) LED on, and are the DSX-1 OOF (out of frame) and ALM (alarm) LEDs off? – If so, the DSX interface is set up correctly and ready to communicate. –...

  • Page 16: Connecting The Modem

    Check Health and Status messages in the left column of the System and Test Status screen for messages. Main Menu Status System and Test Status – If System Operational appears, the Port-1 interface is set up correctly and is operational. –...
  • Page 17 Connecting to the ISDN This procedure only applies to a FrameSaver unit equipped with an ISDN DBM. 1. Insert the 8-pin connector on the ISDN cable into the DBM interface. 2. Insert the other end of the cable into the ISDN service jack. –...
  • Page 18 Check PVC Connections Check PVC connections to verify that all PVCs, including management PVCs, are configured, and to see whether the PVC is active or not. 1. Press Esc to return to the Status menu. 2. Select PVC Connection Status. The PVC Connection Status screen shows all PVC connections;...

  • Page 19: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. This product is intended to be used with a 3-wire grounding type plug – a plug which has a grounding pin. This is a safety feature. Equipment grounding is vital to ensure safe operation.

  • Page 20: Emi Warnings

    The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne. In order to maintain compliance with FCC limits, any supplied ferrite chokes must be installed in accordance with the card installation instructions.

  • Page 21: Government Requirements

    Government Requirements Certain governments require that instructions pertaining to connection to the telephone network be included in the user documentation. Specific instructions are listed in the following sections. United States Notice to Users of the Telephone Network This equipment complies with Part 68 of the FCC rules. On the bottom of the housing is a label that contains, among other information, the FCC registration number for this equipment.
  • Page 22 When the unit has an ISDN PRI DBM, make the ISDN PRI connection using a USOC-type RJ48C jack. When ordering an ISDN line from the telephone company, specify the following: Service Order Code 6.0F Facility Interface Code 04DU-1SN Up to 23B Service for an ISDN PRI DBM – Supports up to 23 circuit-switched B-channels, with one local phone number for the entire T1 network connection.
  • Page 23 Canada Notice to Users of the Canadian Telephone Network The Industry Canada label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction.

  • Page 24: Warranty, Sales, Service, And Training Information

    Document Feedback We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.
