Notes: The revised IP address should be enabled, or you can not succeed in modifications.
(4). After you select the IP address, click the icon of
shown as figure 5:
Check if the IP address shown in the display interface of Ping Device is the only one and enabled for PC
network. If it is correct, click "Close."
(5). Click "Port" at the right corner of the user interface of Lantronix Xport Installer 3.2 so it can display
the user interface of Port Collection Editor, shown as figure 6:
In the user interface of Port Collection Editor, you can set parameters of Baud Rate member, Data Bits
member, Stop Bits member and etc. for situations of actual operations.
2. lantronix Instructions (under the conditions of Xport Installer searching for enabled IP address)
(1). Click"START"
the user interface of Lantronix Redirector Configuration, shown as figure 7:
Figure 4: Revised IP address
Figure 5: Display interface of Ping Device
Figure 6: User interface of Port Collection Editor
"PROGRAM" "lantronix"
Figure7: User interface of Lantronix Redirector Configuration
EXP-TCPIP-BDI/VDI
Ping button displays the information of IP,
"Redirector"
Version：V01 Page：4
"Configuration" and enter
