1. Xport Installer Instructions

(1). Click "START"
of Lantronix Xport Installer 3.2, shown as figure 2:
(2). Click the icon of
A. IP Address:
Each EXP-TCPIP-BDI/VDI will search out the unique IP address which will be in the same subnet as
PC and is the only one, different from other IP addresses.
B. Hardware Address:
Format: 00-20-4A-XX-XX-XX,"XX"presents the unique one.
(3). While you select the IP address, click the icon of
EXP-TCPIP-BDI/VDI.
For example: Modifying the following IP address to "10.128.19.12."
Click "OK" and you succeed in modification of IP address. You search for IP again and you can find that IP
address has been changed to "10.128.19.12," shown as figure 4.
"PROGRAM" "Xport Installer"
Figure 2: User interface of Lantronix Xport Installer 3.2
, then you can search for the IP address of EXP-TCPIP, shown as figure 3:
Figure 3: Searching for IP address of EXP-TCPIP-BDI/VDI
EXP-TCPIP-BDI/VDI
"Xport Installer" and enter the user interface
and you can modify the IP address of
