- Page 1 Performer 200 Quad User Manual Order code: LEDJ490...
-
Page 2: Safety Advice
Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and/or property. www.prolight.co.uk Performer 200 Quad User Manual... - Page 3 Performer 200 Quad Featuring a huge 200W output, stylish housing and unsurpassed colour mixing via COB (Chip-on-Board) technology the Performer 200 Quad creates rich hues, colour changes and smooth fades from the 4-in-1 RGBW light source. Its output is comparable to a 1000W halogen sealed beam Par thanks to its special parabolic reflector which develops an extremely bright and homogenous output.
-
Page 4: Technical Specifications
07 - PowerCON output 08 - Fuse: F4A 250V 09 - Hanging bracket 10 - Hanging bracket adjustable knob In the box: 1 x fixture, 1 x power cable & 1 x user manual www.prolight.co.uk Performer 200 Quad User Manual... - Page 5 000-049 No function 050-099 Colour change 100-149 Colour fade 150-199 Colour fade in/out 200-255 Sound active 000-255 Chase/fade speed (slow to fast) 000-255 Red (0-100%) 000-255 Green (0-100%) 000-255 Blue (0-100%) 000-255 White (0-100%) www.prolight.co.uk Performer 200 Quad User Manual...
-
Page 6: Master/Slave Mode
To access the sound active mode, press the “MENU” button on the rear of the unit to show on the LED display. The unit will now respond to sound. To exit out of any of the above options, press the “MENU” button. www.prolight.co.uk Performer 200 Quad User Manual... -
Page 7: Dmx Setup
Please quote: 3-Pin: CABL10 – 2m CABL11 – 5m CABL12 – 10m 5-Pin: CABL185 – 2m CABL187 – 5m CABL188 – 10m Also remember that DMX cable must be daisy chained and cannot be split. www.prolight.co.uk Performer 200 Quad User Manual... -
Page 8: Line Termination
5-pin XLR (male) 3-pin XLR (female) Pin 1: GND (screen) Pin 1: GND (screen) Pin 2: Signal (-) Pin 2: Signal (-) Pin 3: Signal (+) Pin 3: Signal (+) Pin 4: N/C Pin 5: N/C www.prolight.co.uk Performer 200 Quad User Manual... - Page 9 Please note: Caution should be used when power linking other fixtures to the Performer 200 Quad as the power consumption of other fixtures will vary. Fixtures fitted with lamps often require 2/3 times more current on startup, these may require their own power source.
-
Page 10: Weee Notice
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. www.prolight.co.uk Performer 200 Quad User Manual... - Page 11 Performer 200 Quad User Manual...
- Page 12 Performer 200 Quad User Manual...
