I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
LCD Display Static Mount
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
PSM2613

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSM2613 and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF PSM2613

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation LCD Display Static Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PSM2613...
  • Page 2 It is the CAUTIONS! installer’s responsibility to make sure the combined weight of all components located between the PSM2613 up to (and including) the display does not exceed 150 lbs (68.04 kg). WARNING:...
  • Page 3 Installation Instructions PSM2613 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
  • Page 4 PSM2613 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 7/32" (5.5mm) 1/2" (12.7mm) PARTS A (1) [PSM2613 bracket] C (1) D (1) E (1) #10-24 x 1/2" [spacer] #10-24 B (1) [latching flag] G (6) F (6) [mounting button] M6x30mm...
  • Page 5: Assembly And Installation

    It is the installer’s responsibility to make sure the combined weight of all components located between the PSM2613 up to (and including) the display does not exceed 150 lbs (68.04 kg). Use with products heavier than the maximum weight indicated may result in collapse of the mount and its accessories causing possible injury.
  • Page 6 PSM2613 Installation Instructions...
  • Page 7 Installation Instructions PSM2613...
  • Page 8 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
