CHIEF PSM-2124 Installation Instructions

I N S T A L L A T I O N I N S T R U C T I O N S
(1) Static Mount
(1) Latching Flag
(4) M6 X 25mm Phillips Head Cap Screws
(4) Mounting Buttons
BEFORE PROCEEDING: Unpack the carton, verify contents shown in Figure 1 and read
installation instructions completely. If you are missing any of the listed components, please
contact Customer Service at 1-800/582-6480.
CAUTION!
1. Attach latching flag to mount using the 10-24 screw, Nylon washer, and Nylock nut (see
Figure 2). Tighten until friction will hold the flag in place.
2. Attach mounting buttons to the display using the M6 screws provided (see Figure 3 &
Figure 4).
Figure 2
DISPLAY STATIC MOUNT
PSM-2124
Figure 1
Displays are Extremely Fragile.
Figure 3
