- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Large Flat Panel Static Wall Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PSMH2685...
- Page 2 2,000lbs (907.185kg). Reinforce ®Chief is a registered trademark of Milestone AV Technologies. the structure as required before installing the mount. All rights reserved.
- Page 3 Installation Instructions PSMH2685 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 4: Assembly And Installation
PSMH2685 Installation Instructions ASSEMBLY AND INSTALLATION Mount Installation Mount Assembly WARNING: IMPROPER INSTALLATION CAN LEAD TO Attach one security latch (C) to each vertical bracket (B) MOUNT FALLING CAUSING SERIOUS PERSONAL using one 1/4-20 x 3/4" button head cap screw (H) and one 1/4-20 nylon lock nut (E) for each vertical bracket. - Page 5 Installation Instructions PSMH2685 (8 circled locations) Figure 3 CAUTION: IMPROPER INSTALLATION CAN LEAD TO MOUNT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! DO NOT overtighten hardware! Secure mount to studs using appropriate hardware for mounting surface. (See Figure 4)
- Page 6 PSMH2685 Installation Instructions Display Installation Move display forward until recessed area of mounting buttons is positioned over lower area of teardrop mounting holes. (See Figure 7) WARNING: IMPROPER INSTALLATION CAN LEAD TO Lower display until recessed area of mounting buttons is seated in lower area of teardrop mounting holes.
- Page 7 Installation Instructions PSMH2685...
