Summary of Contents for CHIEF PSMH2465
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Large Flat Panel Landscape/Portrait Static Wall Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PSMH2465...
-
Page 2: Installation Instructions
900 lbs (408.2 kg). Reinforce the Chief® is a registered trademark of Milestone AV Technologies. structure as required before installing the component. The All rights reserved. - Page 3 Installation Instructions PSMH2465 DIMENSIONS PSMH2465 - LANDSCAPE DIMENSIONS: [MILLIMETERS] INCHES PSMH2465 - PORTRAIT DIMENSIONS: [MILLIMETERS] INCHES...
-
Page 4: Tools For Installation
PSMH2465 Installation Instructions TOOLS FOR INSTALLATION 7/32" 1/4" 1/4" 5/16" 1/4" PARTS A (1) [Wall Mount] C (2) B (2) [Landscape Flag] [Portrait Flag] D (4) [Mounting Button] E (2) 10-24 x 1/2" G (2) J (4) F (4) K (4) -
Page 5: Assembly And Installation
(See Figure 2) The PSMH2465 is designed to allow the display to be mounted in either the Landscape or Portrait mode on either a 16" or 24" Using a pencil or similar marking tool, mark the location of on-center wood stud or steel stud wall. - Page 6 PSMH2465 Installation Instructions Steel Stud Wall WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum requirements for installation of display mounts onto a steel stud structure. If the structure or its components do not meet these requirements contact the mount manufacturer for specific instructions before attempting installation.
- Page 7 Installation Instructions PSMH2465 WARNING: Steel Stud IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL Drywall INJURY OR DAMAGE TO EQUIPMENT! It is the installer’s responsibility to make sure the structure to which this mount Plastic Cap is being attached can support a minimum of 900 lbs (408.2 kg).
-
Page 8: Installing Display
PSMH2465 Installation Instructions Installing Display WARNING: IMPROPER INSTALLATION CAN LEAD TO MOUNT FALLING CAUSING SEVERE PERSONAL INJURY WARNING: IMPROPER INSTALLATION CAN LEAD TO OR DAMAGE TO EQUIPMENT. Displays can weigh in MOUNT FALLING CAUSING SERIOUS PERSONAL excess of 210 lbs (95.3 kg). ALWAYS use at least two people INJURY OR DAMAGE TO EQUIPMENT! DO NOT substitute and proper lifting techniques when installing display. - Page 9 Installation Instructions PSMH2465 Portrait Mount Attach locking flag (B) to wall mount (A) vertical bracket using one 10-24 x 1/2" button head cap screw (E), one .194 x .375 x .032" spacer (H), and one 10-24 lock nut (G) through lower hole on locking flag and upper hole on wall mount vertical bracket.
- Page 10 PSMH2465 Installation Instructions Steel Stud Wall Installing Display WARNING: WARNING: IMPROPER INSTALLATION CAN LEAD TO IMPROPER INSTALLATION CAN LEAD TO MOUNT FALLING CAUSING SERIOUS PERSONAL EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! DO NOT substitute INJURY OR DAMAGE TO EQUIPMENT! Figure 4 identifies hardware.
- Page 11 Installation Instructions PSMH2465 WARNING: IMPROPER INSTALLATION CAN LEAD TO lock here (optional) MOUNT FALLING CAUSING SEVERE PERSONAL INJURY OR DAMAGE TO EQUIPMENT. Displays can weigh in excess of 210 lbs (95.3 kg). ALWAYS use at least two people and proper lifting techniques when installing display.
- Page 12 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 Chief Manufacturing, a products division F +31 (0)40 2668615 of Milestone AV Technologies Asia Pacific A Office No. 1 on 12/F, Shatin Galleria...
