- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Large Flat Panel Static Wall Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PSMH2485...
-
Page 2: Installation Instructions
2,000lbs (907.185kg). Reinforce ®Chief is a registered trademark of Milestone AV Technologies. the structure as required before installing the component. All rights reserved. - Page 3 Installation Instructions PSMH2485 DIMENSIONS 2134 84.00 12.24 2.85 2.65 5.73 7.97 Manufacturer recommends 200 mm(7.97") clearance between the back of the screen and the wall 35.00 1035 2.73 29.25 40.75 1149 45.25 DIMENSIONS: [MILLIMETERS] INCHES 1601 63.05 1423 56.01 29.25 35.00...
- Page 4 PSMH2485 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Assembly And Installation
Installation Instructions PSMH2485 ASSEMBLY AND INSTALLATION Mount Installation Mount Assembly WARNING: IMPROPER INSTALLATION CAN LEAD TO Attach two vertical brackets (A) to two horizontal brackets MOUNT FALLING CAUSING SERIOUS PERSONAL (B) using sixteen 5/16-18 nylon lock nuts (F). (See Figure 1) -
Page 6: Display Installation
PSMH2485 Installation Instructions CAUTION: IMPROPER INSTALLATION CAN LEAD TO MOUNT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! DO NOT overtighten hardware! Secure mount to studs using 5/16 x 2-1/2" lag screws [not included] and 5/16" flat washers [not included] (8 if 24"... - Page 7 Installation Instructions PSMH2485 (H) x 2 (C or D) x 4 (E) x 2 Figure 5 Padlock Here CLOSE Q-Latch Figure 6 Move Q-Latches to Closed position and lock if desired. Figure 7 (See Figure 7) Route wires and cables to display.
- Page 8 A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands Chief Manufacturing, a products P +31 (0)40 2668620 division of Milestone AV Technologies F +31 (0)40 2668615 Asia Pacific A Office No.
