Summary of Contents for Raisecom ISCOM2109F
- Page 1 ISCOM2109F Hardware Installation User Manual...
- Page 2 Raisecom Technology Co., Ltd shall not be held liable for errors contained herein or direct, indirect, special, incidental or consequential damages in connection with the furnishing, performance, or use of this material.
- Page 3 Tel: +86-10-82883305 Fax: +86-10-82883056 World Wide Web You can access the most current Raisecom product information on the World Wide Web at the following URL: http://www.raisecom.com Feedback Comments and questions about how the ISCOM2109F device works are welcomed. Please review...
-
Page 4: Table Of Contents
CONTENTS General Safety Instructions ------------------------------------------------------------------------------ 1 Chapter 1 Overview ------------------------------------------------------------------------------------- 3 1.1 Overview of this manual -----------------------------------------------------------------------------------------------------3 1.2 Terms explanation-------------------------------------------------------------------------------------------------------------3 Chapter 2 Specification and Dimension ---------------------------------------------------------- 4 2.1 Device hardware description -----------------------------------------------------------------------------------------------4 2.2 Device dimension -------------------------------------------------------------------------------------------------------------4 2.3 Device operating environment ---------------------------------------------------------------------------------------------4 2.4 Technical parameter ----------------------------------------------------------------------------------------------------------4 Chapter 3 Device Appearance ----------------------------------------------------------------------- 5... -
Page 5: General Safety Instructions
User Manual General Safety Instructions The following instructions serve as a general guide for the safe installation and operation of telecommunications products. Additional instructions, if applicable, are included inside the manual. Safety Symbols This symbol may appear on the equipment or in the text. It indicates potential safety hazards regarding product operation or maintenance to operator or service personnel. - Page 6 User Manual be present inside certain products even when the power switch (if installed) is in the OFF position or a fuse is blown. For DC-powered products, although the voltages levels are usually not hazardous, energy hazards may still exist.
-
Page 7: Chapter 1 Overview
Chapter 1 Overview 1.1 Overview of this manual This manual mainly discusses the installation of ISCOM2109F switch. It describes the features of the switch, introduces its components and the functions these components accomplish. The manual brings forth a normative installation procedure for users and explains the types and specifications of all cables applied during the installation. -
Page 8: Chapter 2 Specification And Dimension
Chapter 2 Specification and Dimension 2.1 Device hardware description ISCOM2109F Ethernet Switch is a layer-2 Ethernet switch designed for network users’ access to the carriers’ network. ISCOM2109F provides 8 100BASE-FX Ethernet interfaces and 1 expansion socket which can be configured to interface for 1000BASE-TX, 1000BASE-FX, or 100BASE-FX cards. -
Page 9: Chapter 3 Device Appearance
Chapter 3 Device Appearance 3.1 Device front panel description 8 100BASE-FX Ethernet interfaces, 1 expansion socket for sub cards, 1 CONSOLE interface and dozens of status indicators are placed on the front panel of ISCOM2109F switch (see the figure below). ISCOM2109F... -
Page 10: Device Rear Panel Description
⑤ 1 expansion interface for sub cards. 3.2 Device rear panel description ISCOM2109F provides sockets for both 220V AC power supply and 48V DC power supply on its rear panel (see the figure below). 1) The location for the socket for 220V AC power supply on the device rear panel is shown in the... -
Page 11: Chapter 4 Installation And Application
User Manual Chapter 4 Installation and Application 4.1 Before the installation Before the installation, please be sure that whether there’s any sub card need to be installed. 1) Type of sub cards that can be provided Sub Card Model... - Page 12 User Manual Ethernet at 10Mbps. When the port is in Link Up status, it indicates that the port is not connecting to the Ethernet at the rate of 10Mbps. 100M Green The corresponding port is connecting to the Ethernet at the rate of 100Mbps.
-
Page 13: Device Installation
4.2 Device installation 4.2.1 Environment requirement There are heat exhaust outlets on both sides of ISCOM2109F switch. Please leave space on both sides of the switch to keep air flow unblocked. Please make sure the outlets are not blocked. 4.2.2 Install the device on to a rack To set the switch firmly into a rack, please fix the installation tray to the switch using the four screws come with the device and fasten the installation handle on to the rack. - Page 14 The pin number and pin function definition of 9-pin serial port connector is shown in the figure and table below. Function Type Function Type Number Number Ground CONSOLE interface connecting pattern and parameter setup The connecting of ISCOM2109F CONSOLE interface and PC serial port is shown in the figure...
-
Page 15: Connect To Ethernet
They connect to 100BASE-FX optical interfaces on other devices using fiber. 4.3.3 Connect to the power supply 1) ISCOM2109F adopts 220V AC power supply. Please connect the socket on the rear panel of the switch with 220V AC power supply using the provided power supply cable. - Page 16 User Manual terminal software is correctly configured, the user management interface on which users can operate over the switch will appear on the PC (For details, please refer to the corresponding software configuration manual.).
-
Page 17: Chapter 5 Notes
User Manual Chapter 5 Notes The installation, maintenance, plugging in and pulling out of components of ISCOM2109F switch can only be conducted by qualified technical support staff. Please place the device in a temperature-controllable and humidity-controllable room and please be cautious of the conductivity of the materials around the device. - Page 18 Address: 2 Floor, South Building of Rainbow Plaza, No.11 Shangdi Information Road, Haidian District, Beijing Postcode: 100085 Tel: +86-10-82883305 Fax: +86-10-82883056 Email: export@raisecom.com http://www.raisecom.com...
