ADJUSTMENT
Pitch
1. Loosen pitch adjustment knob.
2. Tilt display to desired angle (-15° to +15°).
3. Tighten pitch adjustment knob.
Extension and Swivel
WARNING:
Excessive loosening or tightening of
adjustment screws can result in serious personal
injury or damage to equipment!
1. Using appropriate hex key, loosen or tighten
adjustment screws as required to achieve desired
tension.
