I N S T A L L A T I O N I N S T R U C T I O N S
Top Down Desk Mount Bracket Accessory
Model: MSP-DARAC1B
Specifications:
•
Designed for top-down installation of KCS-110
mount.
•
Weight capacity of 40 lbs (18 kg).
BEFORE YOU BEGIN
WARNING: It is the installer's responsibility to make sure all components are properly assembled and installed
using the instructions provided. Failure to read, thoroughly understand, and follow all instructions can result in
serious personal injury, damage to equipment, or voiding of factory warranty.
•
If you have any questions about this these instructions or your specific installation, contact Chief Manufacturing
at 1-800-582-6480 or 952-894-6280.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE 700
SAVAGE, MINNESOTA 55378 USA
MSP-DARAC1B
(Shown installed on KCS-110, purchased separately)
8832-000162
2006 Chief Manufacturing
www.chiefmfg.com
04/06
Advertisement
Related Manuals for CHIEF MSP-DARAC1B
Summary of Contents for CHIEF MSP-DARAC1B
- Page 1 Failure to read, thoroughly understand, and follow all instructions can result in serious personal injury, damage to equipment, or voiding of factory warranty. • If you have any questions about this these instructions or your specific installation, contact Chief Manufacturing at 1-800-582-6480 or 952-894-6280. CHIEF MANUFACTURING INC.
- Page 2 WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components attached to the MSP-DARAC1B (including the mount and display) does not exceed 40 lbs (18 kg).
- Page 3 PARTS Clamp attach After unpacking carton, inspect and verify contents (See screw Figure 1). If any listed parts are missing or damaged, contact Chief Customer Service at 1-800-582-6480. Table 1: Parts Item Description BRACKET, Top Down Desk Mount SCREW, Phillips Pan Sheet Metal, #10 x 1-1/2"...
- Page 4 1. Determine approximate location for mount keeping in NOTE: Clamp attach screw, washer, and clamp will not mind display size, arm extension, and pitch/roll be reused in MSP-DARAC1B installation. requirements. However, if desired, attach screw can be inserted 2. Using bracket (10) as a template, mark location of in bore for appearance only.
