Summary of Contents for CHIEF MSPDCCS4
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Large Flat Panel Swingarm Wall Mount MSPDCCS4...
-
Page 2: Important Warnings And Cautions
MSPDCCS4 Installation Instructions DISCLAIMER WARNING: Failure to read, thoroughly understand, and CSAV, Inc., and its affiliated corporations and subsidiaries follow all instructions can result in serious personal injury, (collectively, "CSAV"), intend to make this manual accurate and damage to equipment, or voiding of factory warranty! It is the complete. - Page 3 Installation Instructions MSPDCCS4 LEGEND Pencil Mark Tighten Fastener Marcar con lápiz Apretar elemento de fijación Stiftmarkierung Befestigungsteil festziehen Marcar com lápis Apertar fixador Segno a matita Serrare il fissaggio Potloodmerkteken Bevestiging vastdraaien Marquage au crayon Serrez les fixations Drill Hole...
-
Page 4: Tools Required For Installation
MSPDCCS4 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 9/16" (14.3mm) 1/4" (6.4mm) 7/16" (11.1mm) 3/8" (9.5mm) 1/2" (12.7mm) D (4) A (1) B (1) C (4) D (4) E (1) 5/32" F (1) 3/16" G(1) 7/32" M (1) L (4) N (1) - Page 5 Installation Instructions MSPDCCS4 INSTALL ARM ASSEMBLY/WALL PLATE TO WALL Wood Installation WARNING: Failure to provide adequate structural 1/4" strength for this component can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the structure to which this...
- Page 6 MSPDCCS4 Installation Instructions INSTALL COVER PLATES L x 4 Install four cover plates (C) using four screws (L) and four spacers (P). Insert screw into cover plate and add the spacer before inserting the cover plate tab into the Place tab arm assembly.
-
Page 7: Cable Management
Installation Instructions MSPDCCS4 INSTALL DISPLAY TO ARM/WALL PLATE ASSEMBLY WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components attached to the mount does not exceed 125 lbs (56 kg). - Page 8 MSPDCCS4 Installation Instructions ADJUSTMENT Pitch Loosen pitch adjustment knob. Tilt display to desired angle (-15° to +15°). -15° Tighten pitch adjustment knob. 0° +15° Extension and Swivel WARNING: Excessive loosening or tightening of adjustment screws can result in serious personal...
- Page 9 Installation Instructions MSPDCCS4...
- Page 10 F +31 (0) 40 2668615 Asia Pacific A Room 30I, Block D, Lily YinDu International Building LuoGang, BuJi Town, Shenzhen, CHINA. Post Code: 518112 8805-000227 2007 Chief Manufacturing www.chiefmfg.com P +86-755-8996 9226 ; 8996 9236 ; 8996 9220 02/07 F +86-755-8996 9217...
