- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Office Furniture Array Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description MSP-WL4...
-
Page 2: Important Safety Instructions
It is the installer’s responsibility to make sure the combined weight of DEFINITIONS all components attached to the MSP-WL4 mount up to (and MOUNTING SYSTEM: A MOUNTING SYSTEM is the including) the display does not exceed 15 lbs (6.8 kg) per primary Chief product to which an accessory and/or component display and 30 lbs (13.6 kg) total. - Page 3 Installation Instructions MSP-WL4 DIMENSIONS 19.0 MAX. 4.2 MIN. 26.0 6.50...
-
Page 4: Installation Instructions
MSP-WL4 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación... -
Page 5: Tools Required For Installation
Installation Instructions MSP-WL4 TOOLS REQUIRED FOR INSTALLATION 1/2” 3/16” (included) 1/8” (included) 5/32” (included) PARTS T (1) 3/16” A (1) [Arm assembly] U (1) D (8) E (1) 5/32” B (8) C (8) M10x5.3x10 #10-32 x 3/8" M4x25mm M4x14mm V (1) 1/8”... -
Page 6: Assembly And Installation
MSP-WL4 Installation Instructions Assembly And Installation Tighten two upper and lower button head cap screws to secure OFBU bracket to wall. (See Figure 3) Connecting K1S Series to Office Furniture Verify mounting brackets on OFBU bracket on mounting arm (A) can move freely. (See Figure 1) -
Page 7: Array Installation
(H), pivot point spacer (R) and 5/16-18 lock nut (K) to all components attached to the MSP-WL4 mount up to (and secure array (E) to arm assembly (A). (See Figure 4) including) the display does not exceed 15 lbs (6.8 kg) per... -
Page 8: Handle Installation
MSP-WL4 Installation Instructions For recessed mounting hole installation: Handle Installation • Place four spacers (D) on top of mounting holes Loosen four screws securing handle brackets to array arm on back of display. (See Figure 7) (E). (See Figure 9) •... -
Page 9: Display Adjustments
Installation Instructions MSP-WL4 Adjustments Rotational Adjustment NOTE: (Optional) Rotational adjustment may be locked by installing rotational locking screw (X) into back of faceplate. (See Figure 11) Figure 11 Figure 13 The monitor may be adjusted 90 degrees in either direction Array Bar Roll Adjustment in order to provide a portrait view of the monitor. - Page 10 MSP-WL4 Installation Instructions Swing Arm Pivot Adjustment Adjust pivot position as desired. (See Figure 15) Adjust pivot point tension screws to change pivot adjustment tension. (See Figure 15) pivot point tension Figure 15 Cable Management Install array cable clips (L) to back of array. (See Figure 16) Route cables through array cable clips (L) as desired.
- Page 11 Installation Instructions MSP-WL4...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
