I N S T A L L A T I O N I N S T R U C T I O N S
Touch Screen Stand
Model: MSP-WRTS1
The WRTS1 is a free standing solution for point of
purchase displays.
BEFORE YOU BEGIN
CAUTION: To prevent damage to the Kit, which could affect or void the Factory warranty, and to the equipment that
will be attached to it, thoroughly study all instructions and illustrations before you begin the installation.
•
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE 700
SAVAGE, MINNESOTA 55378 USA
8805-000170 Rev B
2006 Chief Manufacturing
www.chiefmfg.com
01/07
Advertisement
Related Manuals for CHIEF MSP-WRTS1
Summary of Contents for CHIEF MSP-WRTS1
- Page 1 CAUTION: To prevent damage to the Kit, which could affect or void the Factory warranty, and to the equipment that will be attached to it, thoroughly study all instructions and illustrations before you begin the installation. • If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480. CHIEF MANUFACTURING INC. 8805-000170 Rev B...
-
Page 2: Important Warnings And Cautions
WARNING: Watch for pinch points. Do not put your fingers between movable parts. TOOLS REQUIRED FOR INSTALLATION PARTS • 9/16" Wrench Unpack carton, inspect and verify contents. Read installation instructions completely. If any listed parts are • 7/32" Hex Key (provided) missing, contact Chief Customer Service at 1-800-582- • Phillips Screwdriver 6480. -
Page 3: Installation Instructions
*250 WASHER, Flat, M4 (included but Not shown) NUT, Acorn, 3/8-16 *260 SCREW, Phillips Pan Head, 8-32 x 5/8" (included but Not shown) *270 WASHER, Flat, #8 (included but Not shown) * indicates hardware used for mounting od display to the MSP-WRTS1. Figure 1: PARTS... -
Page 4: Assembly And Installation
Model: MSP-WRTS1 Installation Instructions ASSEMBLY AND INSTALLATION 10. Secure support (110) bar to L.H. upright (100) using one LW (140) and one HHCS (120). (see Figure 3) Assemble Stand Base 11. DO NOT tighten hardware at this time. 1. Align mounting holes in R.H. upright (100) with mounting holes in R.H. - Page 5 Installation Instructions Model: MSP- Assemble CPU Holder to Faceplate Install Speaker Brackets 1. Align mounting holes in CPU holder assembly (10) 1. Install speaker bracket assemblies (40 and 300) to with mounting holes in faceplate (50). (see Figure 5) CPU Holder assembly (10) using four PPMS (200). (see Figure 6) 2.
- Page 6 Model: MSP-WRTS1 Installation Instructions...
