CHIEF MSP-DCCGPM-210 Installation Instructions Manual

Flat panel tilt wall mount

Advertisement

Quick Links

I N S T A L L A T I O N
Flat Panel
Tilt Wall Mount
MSP-DCCGPM-210
The tilt wall mount fits most 23" to 30" displays.
The mount is designed to adapt to VESA® 200mm/100mm
compliant displays. This mount will also adapt to standard
VESA® 75mm/100mm compliant displays.
The mount allows the user to adjust the viewing angle of the
+
mount
15 degrees hand. The maximum load capacity of the
mount is 45 lbs. (20.4kg).
After adjusting the display to the desired angle, the user can lock
the mount into a fixed position. The user can easily remove the
display from the wall bracket when the mount is unlocked.

BEFORE YOU BEGIN

CAUTION: To prevent damage to your display, which could affect or void the Factory warranty,
thoroughly study all instructions and illustrations before you begin to install the mount brackets. Pay
particular attention to the "Important Warnings and Cautions" on Page 2.
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-582-6480.
If a defect is discovered after Dell's initial 21-day Customer Satisfaction period, Chief Mfg. will, at its option, repair
or repair the product at not charge provided it is returned during the warranty period. Please note contact
information for Chief Mfg. listed below.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE. 700
SAVAGE, MINNESOTA 55378 USA
I N S T R U C T I O N S
MSP-DCCGPM-210
8832-000080 (Rev. A)
2005 Chief Manufacturing
www.chiefmfg.com
04/05
